OMRON G5RL1AELNDC12 PCB Power Relay
The G5RL PCB Power Relay is a reliable, compact low-profile relay designed for industrial automation and control applications. With a height of just 15.7 mm, it features options for AC coils, high-inrush currents up to 100 A, and low noise variants producing significantly less sound pressure. Its robust construction provides an 8 mm creepage distance, 10 kV impulse withstand voltage, and RoHS compliance, making it suitable for diverse environments including control panels, HVAC systems, and automation equipment. The relay offers multiple contact configurations, high dielectric strength, shock resistance, and durability for heavy-duty switching tasks.
OMRON G5RL1AELNDC12 PCB Power Relay Specifications:
- Height: 15.7 mm
- Creepage distance: 8 mm
- Impulse withstand voltage: 10 kV
- Coil voltages available: 5VDC, 12VDC, 24VDC, 48VDC, AC options
- Contact ratings: 12 A at 250 VAC resistive load, 16 A at 250VAC, 24 VDC
- Max switching capacity: 16 A at 250 VAC, 24 VDC for resistive loads
- Operating temperature: -40°C to 85°C
- Durability: Mechanical 10,000,000 operations, Electrical 100,000 operations
- Dielectric strength: 6,000 VAC for 1 min
- Shock resistance: 15 ms max., vibration resistance: 10 to 55 Hz, 0.75 mm amplitude
- Certification: UL, CSA, RoHS compliant
- Dimensions: Approx. 23.0 mm x 20.0 mm x 15.7 mm
- Insulation resistance: 1,000 MΩ min. at 500 VDC
- Material: Reinforced insulation, coil resistance varies per voltage
Buy the OMRON G5RL – Reliable PCB Power Relay for Industrial Applications
Enhance your control systems with the OMRON G5RL PCB Power Relay, renowned for its compact size, high durability, and reliable switching capacity. This low-profile relay is ideal for industrial automation, HVAC, and control panels, offering options for high-inrush and low noise variants. With RoHS compliance and robust electrical ratings, it ensures safety and performance in demanding environments. Purchase online today and secure a dependable relay designed to meet your automation and control needs efficiently and cost-effectively.
Order your OMRON G5RL PCB Power Relay today and ensure dependable control performance in your industrial automation projects.
Frequently Asked Questions
Where can I buy OMRON G5RL1AELNDC12?
You can click on the BUY or RFQ button to purchase G5RL1AELNDC12 from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part G5RL1AELNDC12?
You can download the G5RL1AELNDC12 datasheet or visit the OMRON website for support.
Who is the manufacturer of G5RL1AELNDC12?
OMRON
