OMRON G5RL1EHRDC5 PCB Power Relay
The G5RL series PCB power relay is a compact, low-profile device designed for reliable switching in industrial automation and control applications. It features various models including high-inrush, low noise, and UL-rated versions, with coil voltages ranging from 5VDC to 240VAC. With a creepage distance of 8mm and impulse withstand voltage of 10 kV, these relays offer excellent electrical performance, durability, and safety compliance. Suitable for automation, control panels, and contactor applications, the G5RL relay ensures high reliability in both low and high-current switching scenarios.
OMRON G5RL1EHRDC5 PCB Power Relay Specifications:
- Height: 15.7 mm
- Creepage distance: 8 mm
- Impulse withstand voltage: 10 kV
- Coil voltages: 5VDC, 12VDC, 24VDC, 48VDC, 100VAC, 115VAC, 120VAC, 230VAC, 240VAC
- Contact ratings: 12 A at 250 VAC, 16 A at 250 VAC, 5 A at 250 VAC/DC
- Operation time: Max. 15 ms
- Release time: Max. 5 ms
- Durability: Up to 10 million operations min.
- Insulation resistance: 1,000 MΩ min.
- Dielectric strength: 6,000 VAC for 1 min
- Vibration resistance: 10-55 Hz, 0.75 mm amplitude
- Shock resistance: 1,000 m/s² min.
- Temperature range: -40°C to 85°C
- RoHS compliant
- Model options include Low Noise, High-inrush, UL-rated, and AC coil versions.
Buy the Omron Series G5RL PCB Power Relay: G5RL1EHRDC5
Order the Omron G5RL series PCB Power Relay online today and benefit from its compact design, high durability, versatile models, and reliable switching performance. Whether you need low noise, high-inrush, or UL-rated versions, this relay provides optimal control for industrial automation, control panels, and contactor applications. With excellent electrical characteristics, safety compliance, and a compact profile of just 15.7 mm height, buying online ensures quick delivery and professional support, making your automation projects more efficient and secure.
Buy Omron G5RL1EHRDC5 now and experience unmatched reliability and performance in industrial control applications.
