OMRON G5RLK1EDC24 PCB Power Relay
The G5RL-U/-K PCB Power Relay is a compact, high-capacity latching relay designed for industrial automation and electronic household applications. It features a 16A high inrush switching current, an 8 mm creepage distance, and supports up to 10 kV impulse withstand voltage. Suitable for TV-8 rated loads, it is RoHS compliant and comes with both single and double-winding configurations. Its robust construction ensures reliable switching, even for capacitor and illumination loads, making it ideal for building automation, power meters, and smart home systems. With UL and CSA certifications, it guarantees safety and durability in demanding environments.
OMRON G5RLK1EDC24 PCB Power Relay Specifications:
- Contact form: SPST-NO (1a) or SPDT (1c)
- Rated voltage: 3VDC, 5VDC, 6VDC, 12VDC, 24VDC
- Contact ratings: 16A at 250VAC, 16A at 24VDC, 5A at 24VDC (NC)
- Max switching power: 250VAC resistive load
- Creepage distance: 8 mm
- Impulse withstand voltage: 10 kV
- Ambient operating temperature: Up to 85°C
- Mounting: PCB terminals
- Certifications: UL Recognized, CSA Certified, VDE Certified
- Durability: up to 50,000 operations depending on model
- Coil resistance: varies with rated voltage, measured at 23°C
- Operating frequency: Up to 20,000 cycles for IEC60669-1 certification
- Shock resistance: 50 m/s² for set, 100 m/s² for reset
- Vibration resistance: 10-55 Hz, 0.75 mm amplitude
- Built for high inrush currents and illumination loads
- Designed for industrial automation, electronics, and appliance control
Buy the Omron G5RL-U-24VDC – Reliable PCB Power Relay for Industrial Applications
Secure your automation projects with the Omron PCB Power Relay G5RL-U-24VDC. Engineered for high inrush loads, this relay offers exceptional durability rated up to 16A at 250VAC. Its compact size and PCB mounting make installation straightforward, while certifications for safety and reliability give you peace of mind. Ideal for building automation, smart home devices, and electronic control systems, this relay ensures consistent performance even under demanding conditions. Purchase online now to enhance your power management solutions with trusted Omron quality, quick delivery, and technical support.
Order your Omron G5RL-U-24VDC Series PCB Power Relay today and ensure dependable switching for your automation and appliance systems.
Frequently Asked Questions
Where can I buy OMRON G5RLK1EDC24?
You can click on the BUY or RFQ button to purchase G5RLK1EDC24 from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part G5RLK1EDC24?
You can download the G5RLK1EDC24 datasheet or visit the OMRON website for support.
Who is the manufacturer of G5RLK1EDC24?
OMRON
