OMRON G6C2117PUSDC12 Power PCB Relay
This general-purpose relay features a 12 V DC coil and a single-pole, single-throw normally open contact along with a normally closed contact. Designed for PCB mounting, it supports a current of up to 8 amps and is suitable for a variety of switching applications. The relay offers reliable operation with a compact size, making it ideal for electronic control systems. Its stable operating function ensures consistent performance in automation, industrial controls, and general electronics. Durable and easy to install, it is perfect for versatile switching needs.
OMRON G6C2117PUSDC12 Power PCB Relay Specifications:
- Coil Voltage: 12 V DC
- Contact Configuration: SPST-NO + SPST-NC
- Maximum Contact Current: 8 A
- Maximum Operating Voltage: 250 VAC
- Contact Material: Silver Alloy
- Packaged for PCB mounting
- Operating Function: Single side stable
- Dimensions: 20.07 L x 14.99 W x 9.91 H mm
- Sealed Type: Semi-sealed and sealed types available
- Contact Resistance: 30 mΩ max
- Operate Time: 10 ms max.
- Release Time: 10 ms max.
- Insulation Resistance: 1,000 MΩ min.
- Dielectric Strength: 2,000 VAC for 1 min.
- Operating Temperature Range: -25°C to +70°C
- Vibration Resistance: 10-55 Hz, 1.50 mm double amplitude
- Shock Resistance: Approx. 100 G
Buy the Buy Omron Power PCB Relay G6C2117PUSDC12 Online
Purchase the Omron Power PCB Relay G6C2117PUSDC12 online today for versatile switching performance. This relay features a 12 V DC coil, supports up to 8 amps current, and is suitable for PCB mounting. Its stable operation and compact size make it ideal for industrial automation, control panels, and electronic projects. With a durable design and sealed options, it ensures reliable switching in various environments. Place your order now and enhance your control system with this high-quality relay that combines efficiency, long service life, and easy installation.
Get Omron G6C2117PUSDC12 today—built for precision, durability, and reliable switching in industrial and electronic control systems.
Frequently Asked Questions
Where can I buy OMRON G6C2117PUSDC12?
You can click on the BUY or RFQ button to purchase G6C2117PUSDC12 from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part G6C2117PUSDC12?
You can download the G6C2117PUSDC12 datasheet or visit the OMRON website for support.
Who is the manufacturer of G6C2117PUSDC12?
OMRON
