OMRON G6CU2117PUSDC3 PCB Relay
This general-purpose PCB relay features a compact design and reliable latching operation with a 3 V DC coil. It includes one normally open and one normally closed contact, rated for 8 amps at 250 VAC. Suitable for PCB mounting, it guarantees high durability with a long mechanical life of over 50 million operations and is compliant with UL, CSA, and VDE standards. Ideal for automation and control applications requiring compact, energy-efficient, and high-current switching performance.
OMRON G6CU2117PUSDC3 PCB Relay Specifications:
- Coil Voltage: 3 V DC
- Contact Configuration: SPST-NO + SPST-NC
- Contact Rating: 8 A at 250 VAC
- Maximum Operating Voltage: 380 VAC, 125 VDC
- Maximum Operating Current: 8 A
- Mechanical Life: >50 million operations
- Electrical Life: Varies with load conditions
- Enclosure Type: PCB mount
- Certification: UL, CSA, VDE
- Size: 20.07 L x 14.99 W x 9.91 H mm
- Weight: Approx. 5.6 g
- Operating Temp. Range: -25°C to +70°C
- Vibration Resistance: 10-55 Hz, 1.50 mm double amplitude
- Shock Resistance: Approx. 100 G
- Dielectric Strength: 2,000 VAC between coil and contacts
- Insulation Resistance: 1,000 MΩ at 500 VDC
Buy the Omron Series G6C PCB Relay: G6CU2117PUSDC3
Order the Omron G6CU2117PUSDC3 PCB relay online today and benefit from a high-current, energy-efficient component that ensures reliable switching. Its compact size and latching coil design make it excellent for space-constrained electronics and automation circuits. Designed for PCB mounting, this relay offers a long mechanical life exceeding 50 million operations, high dielectric strength, and certification compliance including UL, CSA, and VDE standards. Enhance your control panel with this high-performance relay for industrial, automation, and control applications, ensuring durability and efficiency.
Buy Omron G6CU2117PUSDC3 now and experience unmatched reliability and performance in your control and automation systems.
Frequently Asked Questions
Where can I buy OMRON G6CU2117PUSDC3?
You can click on the BUY or RFQ button to purchase G6CU2117PUSDC3 from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part G6CU2117PUSDC3?
You can download the G6CU2117PUSDC3 datasheet or visit the OMRON website for support.
Who is the manufacturer of G6CU2117PUSDC3?
OMRON
