OMRON G6S2F45DC Signal Relay
The G6S series surface-mounting relay is a compact, industry-standard 2-pole relay designed to switch 2A signal loads. It features long terminals for reliable soldering and mounting, space-saving inside-L terminals, and a unique terminal structure that withstands IRS soldering processes. With high dielectric strength (2,000 VAC), impulse withstand voltage (2,500 V, 2 x 10 us), and RoHS compliance, it is suitable for telecommunication, measurement, automation, and industrial applications. Models are available with BSI supplementary insulation certification, ensuring safety and durability in various environments.
OMRON G6S2F45DC Signal Relay Specifications:
- Dimensions: 9.4 mm (H) x 7.5 mm (W) x 15 mm (L)
- Pole Configuration: 2-pole/DPDT
- Contact Resistance: 75 mΩ max
- Dielectric Strength: 2,000 VAC between coil and contacts
- Impulse Voltage Withstand: 2,500 V (2 x 10 us)
- Rated Load: 2A at 30 VAC/VDC
- Operating Voltage: 3 VDC, 4.5 VDC, 5 VDC, 12 VDC, 24 VDC (varies by model)
- Coil Resistance: varies by rated voltage
- Material: Tin-plated contacts, epoxy encapsulation
- RoHS Compliant: Yes
- Insulation Certification: BSI (EN62368-1) for certain models
- Relay Function: Single-side stable, latching (single-winding or double-winding)
- Mounting: Surface-mounting terminals designed for reliable soldering
- Operating Temperature: -40°C to +85°C
- Shock Resistance: 1,000 m/s²
- Vibration Resistance: 10-55 Hz, 2.5 mm amplitude
Buy the OMRON Series G6S Signal Switch: G6S2F45DC
Purchase the OMROM Series G6S relay online now to ensure dependable switching of 2A signal loads in your telecommunication, measurement, automation, and industrial applications. This compact 2-pole relay offers high dielectric strength (2000 VAC), impulse withstand voltage (2500 V), and RoHS compliance, making it ideal for various environments. Available with BSI insulation certification, it features long terminals for easy soldering and mounting. Get this reliable, certification-approved relay now to enhance your system’s safety and performance. Shop online today for quick delivery and technical support.
Order your OMROM Series G6S2F45DC relay today and ensure your industrial projects benefit from reliable switching performance and high insulation standards.
Frequently Asked Questions
Where can I buy OMRON G6S2F45DC?
You can click on the BUY or RFQ button to purchase G6S2F45DC from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part G6S2F45DC?
You can download the G6S2F45DC datasheet or visit the OMRON website for support.
Who is the manufacturer of G6S2F45DC?
OMRON
