OMRON G7L1ATUB200240AC Power Relay
The G7L Series power relay is a high-capacity, high-dielectric-strength relay designed for switching inductive loads with reliability. It features a wide-range AC coil handling 100 to 120 or 200 to 240 VAC at 50/60 Hz, with no contact chattering for momentary voltage drops up to 50%. Made with UL94V-0 flame-resistant materials, the relay offers quick-connect, screw, and PCB terminals, along with optional DIN track mounting. Suitable for industrial automation, motor control, and appliance switching, it ensures safety with a 3mm contact gap and conforms to UL, CSA, TUV, IEC950 standards. Its compact size optimizes switching power for various applications.
OMRON G7L1ATUB200240AC Power Relay Specifications:
- Rated Coil Voltage: 100-120 VAC, 200-240 VAC at 50/60 Hz
- Coil Resistance: Varies with voltage; e.g., 24 VAC typical resistance around 8704 ohms
- Contact Form: SPST-NO, DPST-NO with optional test button
- Contact Ratings: Up to 25A at 277 VAC, resistive and inductive loads
- Insulation Resistance: 3000 MΩ min at 500V DC
- Maximum Switching Voltage: 250 VAC at 30A, 1250 VAC at lower currents
- Operating Time: Max. 30 ms, Release Time: Max. 20 ms
- Weight: Approximately 100 g
- Mounting Options: E-bracket, DIN track, front-connecting socket, PCB terminals
- Materials: UL94V-0 flame-resistant insulators
- Standards: UL, CSA, TUV, IEC950
- Contact Gap: 3 mm for safety
- Durability: 1.8 million operations at rated load
- Adjustable mounting Holes: Yes, with tapped holes for screw mounting
- Environment: Suitable for dry, dust-free environments; avoid high humidity or corrosive gases
Buy the Omron Series G7L Power Relay: G7L1ATUB200240AC
Purchase the Omron G7L series power relay online today for dependable switching power in industrial automation, motor control, and appliance applications. Designed with high dielectric strength and flame-resistant materials, it ensures safety and durability. This relay features wide-range AC coils of 100 to 240 VAC, quick-connect, screw, and PCB terminals, supporting various mounting options including DIN track and front-connecting sockets. Perfect for controlling inductive loads, it offers excellent operational longevity with a maximum of 1.8 million cycles and conforms to international safety standards. Simplify your automation setup—buy now for reliable performance.
Get Omron G7L1ATUB200240AC today—built for industrial automation and reliable switching in demanding applications.
