OMRON H3DKM1ACDC24240 Industrial Timer
The H3DK-M1 series is a versatile multi-range, multi-mode solid-state timer designed for industrial automation applications. It features DIN track mounting, a wide power supply range from 24 to 240 VAC/DC, and multiple operating modes including ON delay, flicker start, signal delay, interval, and one-shot output. Certified for UL, CSA, and EN standards, it offers precise timing with adjustable ranges from 0.1 to 120 seconds, robust construction, and finger-safe terminals. Ideal for control panels requiring reliable, programmable timing functions in heavy industrial, residential, commercial, or light industrial environments.
OMRON H3DKM1ACDC24240 Industrial Timer Specifications:
- Power Supply Range: 24 to 240 VAC/DC, 85-110% of rated voltage, 12 VDC models available
- Control Output: SPDT relay, 5 A at 250 VAC resistive load, 0.15 A at 125 VDC, gold-alloy contacts
- Timing Ranges: 0.1 to 120 seconds with adjustable modes including ON delay, flicker start, signal delay, interval, one-shot
- Accuracy: ±10% of FS, ±0.05 s at 1.2 s range, influence of voltage and temperature within specified limits
- Standards: UL 508, CSA C22.2 No. 14, EN 61812-1, CE Marking, IP30 protection, finger-safe terminals
- Operating Conditions: -20°C to 55°C, humidity 25-85%, storage -40°C to 70°C, no icing
- Dimensions: Approx. 88 mm x 22 mm x 68 mm, DIN track mounting, rugged case
- Insulation Resistance: 100 MΩ at 500 VDC, Dielectric Strength: 2,000 VAC between current-carrying parts and exposed non-current parts
- Vibration and Shock Resistance: 0.75 mm at 10-55 Hz, 1,000 m/s² shock, 10 million mechanical operations
- Standards Compliance: EN 61812-1, EN 55011, EN 61000-3-2, EN 61000-3-3, Immunity: IEC 61000-4 series
Buy the Omron H3DK- Reliable Industrial Timer for Automation Applications
Enhance your control panel with the Omron H3DK-M1 industrial timer, offering durable construction, wide power supply compatibility, multiple timing modes, and certified safety standards. Perfect for heavy industrial, residential, or commercial automation projects, it provides precise timing functions with adjustable ranges from 0.1 to 120 seconds. Easy DIN track mounting and finger-safe terminals make installation straightforward, ensuring reliable operation in demanding environments. Purchase online today to optimize your automation setup with proven Omron quality.
Buy Omron H3DK-M1 series now and experience unmatched reliability and precision in industrial timing control.
Frequently Asked Questions
Where can I buy OMRON H3DKM1ACDC24240?
You can click on the BUY or RFQ button to purchase H3DKM1ACDC24240 from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part H3DKM1ACDC24240?
You can download the H3DKM1ACDC24240 datasheet or visit the OMRON website for support.
Who is the manufacturer of H3DKM1ACDC24240?
OMRON
