OMRON K3MALC24VACDC Temperature Controller
The K3MA-L is a digital temperature controller with a highly visible LCD display and dual-color LEDs, suitable for industrial applications. It features wide input options, including platinum-resistance thermometers and thermocouples, with easy front-panel key operation, auto-flicker suppression, and adjustable temperature units. Its robust design includes a water- and dust-proof front panel, certified for UL, CE, and VDE standards, with various accessories for waterproofing. Capable of accurate, reliable temperature measurement and control for industrial furnaces, moldings, generators, and machinery, it provides maximum/minimum monitoring, input shift adjustments, and adjustable hysteresis for stable performance.
OMRON K3MALC24VACDC Temperature Controller Specifications:
- Supply voltage: 100-240 VAC or 24 VAC/VDC
- Power consumption: Max 6 VA (AC) or 4.5 W (DC)
- Input type: Thermocouple or platinum-resistance thermometer (Pt100, JPt100)
- Input range: -200°C to 1700°C, -199.9 to 3000°F depending on sensor
- Display: 7-segment, character height 14.2 mm, max 4 digits (-1999 to 9999)
- Outputs: Relay contact (SPDT), rated 5 A at 250 VAC/30 VDC, life 100,000 cycles
- Protection: NEMA4X/IP66 front panel, IEC IP20 rearcase, finger protection terminals
- Vibration resistance: 10–55 Hz, 50 m/s^2 for 10 min X, Y, Z axes
- Shock resistance: 150 m/s^2, 3 times each axis
- Operating temperature: -10°C to 55°C, storage: -25°C to 65°C
- Humidity: 25%-85% rh, no condensation
- Certifications: UL61010-1, CSA, EN61326-1, VDE0106
- Memory: Non-volatile EEPROM (100,000 rewrite cycles)
- Display color change: green/red or red/green based on status
- Water- and dust-proof front panel (IP66 equivalent), optional waterproof accessories
Buy the Buy Omron Temperature Controller Part Number K3MA-L-C Online
Get your Omron temperature controller with advanced features including LCD display, waterproof front panel, wide input range, and high accuracy. Perfect for industrial furnace, molding, or power generation temperature monitoring. Easy front-panel operation, max/min display, and adjustable hysteresis help ensure stable performance in demanding environments. Purchase online now to benefit from fast delivery, expert support, and trusted quality, ensuring your projects maintain optimal thermal control and safety standards for efficient operation.
Order your Omron Series K3MA-L-C temperature controller today and ensure precise temperature measurement and reliable control for your industrial processes.
Frequently Asked Questions
Where can I buy OMRON K3MALC24VACDC?
You can click on the BUY or RFQ button to purchase K3MALC24VACDC from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part K3MALC24VACDC?
You can download the K3MALC24VACDC datasheet or visit the OMRON website for support.
Who is the manufacturer of K3MALC24VACDC?
OMRON
