OMRON P2CMESS Relay Socket with Rise-up Terminal
The P2CMESS is a relay socket with Rise-up terminal designed for industrial automation applications. It features UL, CSA, TUV, and Lloyd's certification, ensuring high safety and quality standards. The socket supports a rated voltage of 300 VAC and is compatible with relay series G2R-1-S and G2R-2-S. It offers IP20B contact protection, operates within -25°C to +70°C, and can connect 0.5 to 2.5mm² solid wires. Its robust design ensures reliable operation with high resistance to vibration and shock, making it suitable for various control and automation systems.
OMRON P2CMESS Relay Socket with Rise-up Terminal Specifications:
- Dimensions: 15.6 x 77.6 x 61 mm (W*H*D)
- Rated Voltage: 300 VAC
- Carry Current: 10A (G2R-1-S series), 5A (G2R-2-S series)
- Voltage Pole to Pole: Same pole 1000 VAC 1 min, Different pole 3000 VAC 1 min
- Voltage Coil to Pole: 4000 VAC 1 min
- Insulation Resistance: Min 1,000 Mohm
- Contact Protection Degree: IP20B (IEC 529 — EN 60529)
- Operating Temperature: -25°C to +70°C
- Humidity Range: 5% to 85% (no icing or condensation)
- Wire Range: 0.5 to 2.5mm² solid wire (AWG 20 to 14)
- Number of Wires per Terminal: 2
- Vibration Resistance: 10 to 55 Hz, 0.75 mm single amplitude
- Shock Resistance: 200 m/s² energized, 100 m/s² not energized
- Standards: UL508, CSA C22.2, TUV, Lloyd's, RoHS Certified
Buy the Buy OMRON Relay Socket P2CMESS Online
Order the OMRON relay socket with Rise-up terminals online today. Designed for industrial automation, it offers UL, CSA, TUV certification, IP20 protection, and reliable operation across a wide temperature range. Ideal for control panels, automation systems, and switching applications, this socket connects 0.5 to 2.5mm² wires securely, providing robust mechanical and electrical connections. Trust OMRON’s high-quality components for long-lasting performance, vibration and shock resistance, and safety compliance in your automation projects.
Get OMRON P2CMESS today—built for reliable control and long-lasting durability.
