OMRON PF113AD2 General-purpose Relay
The relay features a versatile design suitable for operation checks in relay sequence circuits, equipped with a built-in mechanical indicator for contact operation verification. Models with latching levers provide operational modes for lock and momentary operation, with built-in indicators for DC and AC voltages. Rated for resistive loads up to 10A at 250 VAC, it includes safety features such as reinforced insulation. Suitable for industrial automation, it is UL and IEC TUV certified, ensuring reliable performance in control and automation systems.
OMRON PF113AD2 General-purpose Relay Specifications:
- Contact Form: DPDT, 3PDT
- Terminals: Plug-in, socket options available
- Mechanical Indicator: Built-in on specified models
- Operation Modes: Lock, momentary
- Rated Load: 10A, 250 VAC resistive; 7A, 250 VAC general use
- Rated Voltage: 6 V, 12 V, 24 V, 48 V, 110 V, 220 V, 240 V AC/DC (see detailed ratings)
- Coil Resistance: Varies with rated voltage, e.g., 6V: 443 mA, 12V: 221 mA, 24V: 110 mA
- Contact Resistance: 700 mΩ max
- Operate Time: AC 20 ms max, DC 30 ms max
- Release Time: 20 ms max
- Insulation Resistance: 100 MΩ min at 500 VDC
- Dielectric Strength: 2,500 VAC between coil and contacts, 1,000 VAC between contacts
- Certification: UL508, IEC61810-1, TUV
- Ambient Temperature: -40°C to 60°C; with LED indicator -25°C to 60°C
- Weight: Approx. 90 g
Buy the Omron Series MK-S: General-purpose Relay with Latching Levers and Mechanical Indicators
Enhance your automation and control systems with the durable and reliable Omron general-purpose relay. Featuring built-in mechanical indicators, optional latching levers, and UL/IEC certifications, this relay is ideal for circuit checks, relay sequencing, and industrial automation. Rated up to 10A at 250 VAC for resistive loads, it ensures safe operation with reinforced insulation and high dielectric strength. Easy to install, versatile, and compliant with safety standards—purchase online today for seamless performance and peace of mind.
Buy Omron MK-S relay with latching lever and built-in indicator now and experience unmatched reliability and performance in your automation systems.
Frequently Asked Questions
Where can I buy OMRON PF113AD2?
You can click on the BUY or RFQ button to purchase PF113AD2 from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part PF113AD2?
You can download the PF113AD2 datasheet or visit the OMRON website for support.
Who is the manufacturer of PF113AD2?
OMRON
