OMRON SS10GL2DBYOMI Micro Switch
This subminiature basic switch offers high reliability and security with a contact gap of 1 mm and operates efficiently with a maximum force of 1.47 N. Suitable for various applications, it features RoHS compliance, multiple actuator and terminal options, and robust design for durability of up to 30 million operations. Ideal for use in electronic control systems, automation, and security circuits, it provides excellent insulation resistance and meets safety standards. Its compact size, diverse terminal configurations, and heat resistance make it a versatile choice for precise switching tasks in demanding environments.
OMRON SS10GL2DBYOMI Micro Switch Specifications:
- Contact Gap: 1 mm
- Maximum Operating Force: 1.47 N (150 gf)
- Releasing Force: 0.25 N (25 gf)
- Overtravel: Min. 0.4 - 1.2 mm
- Operating Position: 8.4 mm to 10.8 mm
- Life Expectancy: 30 million operations
- Insulation Resistance: 100 MΩ min. at 500 VDC
- Dielectric Strength: 1500 VAC for 1 min
- Heat Resistance: Standard 85°C, Heat-resistant 120°C
- Mounting Holes: 2.2 mm diameter, M2.3 screw compatible
- Weight: Approx. 1.6 g for pin plunger models
- RoHS Compliant: Yes
- Operating Speed: 60–400 operations/min.
- Contacts Material: Silver alloy, gold alloy options
- Electrical Rating: 125 VAC to 250 VAC, 0.1 A to 10 A
Buy the Buy OMRON Subminiature Basic Switch Part Number SS10GL2DBYOMI Online
Order the OMRON SS10GL2DBYOMI micro switch online today to enjoy reliable operation in electronic control systems, automation, and security circuits. This compact, RoHS-compliant switch features diverse actuator and terminal options, ensuring versatile application in demanding environments. Designed for up to 30 million operations, it offers excellent insulation resistance and adheres to safety standards. Its robust construction, heat resistance, and precise specifications make it an ideal choice for engineers and technical professionals seeking durable, high-performance switching solutions for industrial equipment and control panels.
Get OMRON SS10GL2DBYOMI today—built for precision and long-lasting durability in electronic and automation applications.
Frequently Asked Questions
Where can I buy OMRON SS10GL2DBYOMI?
You can click on the BUY or RFQ button to purchase SS10GL2DBYOMI from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part SS10GL2DBYOMI?
You can download the SS10GL2DBYOMI datasheet or visit the OMRON website for support.
Who is the manufacturer of SS10GL2DBYOMI?
OMRON
