OMRON VX011A2 snap action switch
This is a snap action switch with a round plunger actuator designed for base mounting. It features an on-moment switch function with a single-pole double-throw circuit and can handle contact currents up to 0.1 Amps. Its compact size and versatile actuator options, including short hinge, hinge, long hinge, simulated roller, and roller levers, make it suitable for various automation and control applications. The switch offers high durability, RoHS compliance, and reliable operation at 600 mechanical cycles per minute, ensuring long-lasting performance in industrial environments.
OMRON VX011A2 snap action switch Specifications:
- Contact Resistance: 30 mΩ max.
- Insulation Resistance: 100 MΩ min. at 500 VDC
- Dielectric Strength: 1,000 VAC between same polarity, 1,500 VAC to ground
- Mechanical Life: 600 operations per minute, 50 million minimum
- Electrical Life: 10 million operations at 30 ops/minute
- Operating Temperature: -25°C to 80°C (no icing)
- Degree of Protection: IEC IP40
- Vibration Resistance: 10 to 56 Hz, 1.5 mm amplitude
- Shock Resistance: 400 m/s² max. for destruction, 100 m/s² for malfunction
- Contact Current: Up to 0.1A depending on model
- Rated Voltage: 125 VAC / 30 VDC for initial contact reliability
- Certifications: UL Recognized, CSA Certified, RoHS Compliant
- Size: Compact with various actuator options, suitable for panel mounting
Buy the Buy Omron Snap Action Switch Part Number VX011A2 Online
Enhance your automation system with the Omron snap action switch. Featuring a round plunger actuator and multiple lever options, this high-quality switch handles contact currents up to 0.1A. Its compact size makes it suitable for various control panels and industrial applications. RoHS compliant, with durability up to 50 million mechanical operations, ensuring reliable performance over long periods. Quick and easy to order online, this switch delivers consistent switching performance, making it an essential component for industrial automation and control systems.
Buy Omron VX011A2 now and experience unmatched reliability, versatile actuator options, and long service life in your automation projects.
Frequently Asked Questions
Where can I buy OMRON VX011A2?
You can click on the BUY or RFQ button to purchase VX011A2 from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part VX011A2?
You can download the VX011A2 datasheet or visit the OMRON website for support.
Who is the manufacturer of VX011A2?
OMRON
