Orion Fans OD251005LB Industrial DC Fan
The DC fan series features brushless motors with options for 5V and 12V operation, available with ball or sleeve bearings. Designed with UL94V-0 plastic frames and impellers, these fans provide reliable airflow for electronic cooling and industrial applications. They offer high static pressure, low noise levels, and long lifespan with up to 60,000 hours durability. Suitable for temperature ranges from -10°C to +70°C, they include features like auto restart, polarity protection, and options for tachometer or PWM control, ideal for active cooling systems.
Orion Fans OD251005LB Industrial DC Fan Specifications:
- Model Numbers: 0D2510-05H, 0D2510-05M, 0D2510-05L, 0D2510-12H, 0D2510-12M, 0D2510-12L, 0D2510-12LL, 0D2510-12MB02A
- Voltage Range: 5V or 12V DC
- Current: 0.10A to 8A depending on model
- Rated Power: up to 1.44 Watts
- Airflow: 15 to 27 CFM
- Noise Level: 16 to 31 dB
- Bearing Types: Ball or Sleeve
- Operating Temperature: -10°C to +70°C
- Storage Temperature: -40°C to +80°C
- Frame & Impeller Material: PBT, UL94V-0 plastic
- Static Pressure: up to 17 H₂O
- Lifespan: 30,000 to 60,000 hours
- Certification: RoHS, CE compliant
- Connection: Lead wires or wire leads, 22-28 AWG
- Dielectric Strength: 500VAC at 1 second
- Insulation Resistance: ≥10 MΩ at 500VDC
Buy the Knight DC Fans 0D2510-05H – Reliable Cooling Fans for Industrial Applications
Upgrade your electronic cooling and industrial projects with our reliable DC fans available in 5V and 12V options. Engineered with durable materials like UL94V-0 plastic, these fans offer high airflow ranging from 15 to 27 CFM, low noise levels, and long lifespan up to 60,000 hours. They feature auto restart, polarity protection, and options such as tachometer or PWM control. Easy to install, these fans operate efficiently between -10°C and +70°C, making them ideal for various cooling applications.
Order your Knight Electronics Series0D2510-05H DC fan today and enhance your electronic cooling projects with dependable airflow and long-lasting performance.
