Panasonic 10SVP4R7M Conductive Polymer Aluminum Capacitor
Panasonic's 10SVP4R7M is a robust surface mount conductive polymer aluminum capacitor, engineered for demanding industrial applications. Featuring a wide operating temperature range (-55°C to +105°C) and capacitance tolerance of ±20%, this capacitor ensures stable performance in diverse environments. Its low dissipation factor and DC leakage current contribute to efficient power delivery and reduced energy loss. Ideal for power supplies, filtering circuits, and other critical applications where reliability is paramount.
Panasonic 10SVP4R7M Conductive Polymer Aluminum Capacitor Specifications:
- Size code: ['A5', 'B6', 'C6', 'E7', 'F8', 'E12', 'F12']
- Categorytemp. range: –55 ℃ to +105 ℃
- Rated voltage range (V): ['4.0 to 16', '4.0 to 20', '2.5 to 20', '4.0 to 20', '4.0 to 20', '2.5 to 20']
- Nominal cap.range (μF): ['3.3 to 33', '10 to 68', '22 to 220', '33 to 330', '56 to 680', '100 to 680', '150 to 1500']
- Capacitance tolerance: ±20 %(120 Hz / +20 ℃)
- DC leakage current: Please see the attached characteristics list
- Dissipation factor (tan δ): Please see the attached characteristics list
- Endurance: +105 ℃ 2000 h,rated voltage applied
- Capacitance change: Within ±20 % of the initial value
- Dissipation factor(tanδ): ≦ 150 % of the initial limit
- DC leakage current (after voltage processing): Within the initial limit
- Damp heat: +60 ℃,90 % to 95 %,1000 h,No-applied voltage
- Dimensions (H): 0.2 max
- Dimensions (W): W
- Dimensions (φD): φD
- Dimensions (L): L
- Dimensions (D±05): D±05
- Dimensions (L<br>|+0.1): L<br>|+0.1
- Dimensions (W±02): W±02
- Dimensions (H±02): H±02
- Dimensions (C±02): C±02
- Dimensions (R): R
- Ripple current*1 (mA rms): ['740', '1100', '1810', '2560', '3700', '4520', '5440']
- ESR*2 (mΩ max.): ['200', '70', '40', '35', '25', '13', '12']
- tan δ*3: ['0.12', '0.15', '0.12', '0.12', '0.12', '0.15', '0.18']
- LC*4 (μA): ['66', '78', '136', '264', '340', '448', '544']
- Min. Packaging Q'ty (pcs): ['2000', '1500', '1000', '1000', '1000', '400', '400', '500']
Buy the 10SVP4R7M PANASONIC Conductive Polymer Aluminum Capacitor | myMectronic
Purchase the Panasonic 10SVP4R7M capacitor securely and conveniently online for your industrial needs.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic 10SVP4R7M?
You can click on the BUY or RFQ button to purchase 10SVP4R7M from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part 10SVP4R7M?
You can download the 10SVP4R7M datasheet or visit the Panasonic website for support.
Who is the manufacturer of 10SVP4R7M?
Panasonic
