Panasonic 16SEPC100MTSS Conductive Polymer Aluminum Capacitor
Panasonic's 16SEPC100M+TSS is a radial lead type conductive polymer aluminum solid capacitor designed for applications requiring high capacitance and low equivalent series resistance (ESR). It boasts a wide operating temperature range (-55°C to +105°C) and is RoHS compliant, making it suitable for environmentally conscious designs. The capacitor's robust construction ensures long-term reliability and stability, making it ideal for power supplies, filtering circuits, and other demanding applications. Refer to the datasheet for detailed specifications and performance characteristics.
Panasonic 16SEPC100MTSS Conductive Polymer Aluminum Capacitor Specifications:
- Rated Voltage: 2.5 to 16 V
- Rated Capacitance: 100 to 2700 μF
- Capacitance Tolerance: +/- 20%
- ESR: 5 mΩ to 24 mΩ
- Ripple Current: 4180 mAr.m.s.
- Leakage Current: See attached characteristics list
- Dissipation Factor: See attached characteristics list
- Endurance: +105 °C, 5000 h
- Damp Heat: +60 °C, 90% to 95%, 1000 h
- Operating Temperature: -55 °C to +105 °C
- Case Size: B9, C55, C6, C9, E7, E9, E12, E13, F13
- Frequency Correction Factor: See datasheet for details
Buy the 16SEPC100M+TSS PANASONIC Conductive Polymer Aluminum Capacitor | myMectronic
Purchase the Panasonic 16SEPC100M+TSS securely and efficiently to ensure your project's success.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic 16SEPC100MTSS?
You can click on the BUY or RFQ button to purchase 16SEPC100MTSS from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part 16SEPC100MTSS?
You can download the 16SEPC100MTSS datasheet or visit the Panasonic website for support.
Who is the manufacturer of 16SEPC100MTSS?
Panasonic
