Panasonic 16SVPC100M Conductive Polymer Capacitor
Panasonic's 16SVPC100M is a surface mount conductive polymer aluminum solid capacitor designed for applications requiring low ESR and high capacitance. It boasts a compact size and robust performance, making it suitable for power supplies, DC-DC converters, and other demanding electronic circuits. The capacitor's RoHS compliance ensures environmentally friendly operation. Refer to the datasheet for detailed specifications and reflow conditions.
Panasonic 16SVPC100M Conductive Polymer Capacitor Specifications:
- Size code: ['B6', 'C6', 'E7', 'E12', 'F12']
- Categorytemperature range: ['–55 °C to +105 °C']
- Rated voltage range: ['2.5 V.DC to 16 V.DC']
- Rated capacitance range: ['39 μF to 180 μF', '68 μF to 560 μF', '120 μF to 680 μF', '270 μF to 1500 μF', '2700 μF']
- Capacitance tolerance: ['±20 % (120 Hz / + 20 °C)']
- Leakage current: Please see the attached characteristics list
- Dissipation factor (tand): Please see the attached characteristics list
- Endurance: +105 °C,2000 h,rated voltage applied
- Capacitance change: Within ±20 % of the initial value
- tand: 26 mΩ max.
- DC leakage current: Within the initial limit
- Damp heat: +60 °C,90 % to 95 %, 1000 h, No-applied voltage
- Ripple current: 1970 mAr.m.s. (100 kHz/20 °C)
- ESR: 30 mΩ max.
- LC: 0.12 μA
- Part number: 2R5SVPC180M
- Packaging Q'ty: 1500
Buy the 16SVPC100M PANASONIC Conductive Polymer Capacitor | myMectronic
Purchase the Panasonic 16SVPC100M securely and reliably through our online store.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic 16SVPC100M?
You can click on the BUY or RFQ button to purchase 16SVPC100M from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part 16SVPC100M?
You can download the 16SVPC100M datasheet or visit the Panasonic website for support.
Who is the manufacturer of 16SVPC100M?
Panasonic
