Panasonic 16SVPK100M Conductive Polymer Aluminum Capacitor
Panasonic's 16SVPK100M series capacitors are surface mount devices designed for applications requiring high voltage and stability. These capacitors feature a conductive polymer aluminum construction, offering improved performance compared to traditional electrolytic capacitors. They are characterized by their high capacitance density, low equivalent series resistance (ESR), and excellent endurance, making them suitable for power supplies, DC-DC converters, and other demanding applications. The capacitors are RoHS compliant and halogen-free, ensuring environmental responsibility. Always consult the manufacturer's datasheet for detailed specifications and application guidelines.
Panasonic 16SVPK100M Conductive Polymer Aluminum Capacitor Specifications:
- Category temp. range: –55℃ to +125℃
- Rated voltage range: 16 V to 50 V
- Nominal cap. range: 10 μF to 100 μF
- Capacitance tolerance: ±20 %(120 Hz / +20℃)
- DC leakage current: Please see the attached characteristics list
- Dissipation factor (tan δ): Please see the attached characteristics list
- Endurance: +125℃1000 h, rated voltage applied
- Damp heat: +60℃, 90 % to 95 % RH, 1000 h, No-applied voltage
- Ripple current: 940 mA rms
- Allowable ripple current: 3000 mA rms
- ESR: 27 mΩ max.
- tan δ: 0.12
- LC: 320 μA
Buy the 16SVPK100M PANASONIC Conductive Polymer Aluminum Capacitor | myMectronic
Purchase the Panasonic 16SVPK100M securely and reliably through our online store.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic 16SVPK100M?
You can click on the BUY or RFQ button to purchase 16SVPK100M from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part 16SVPK100M?
You can download the 16SVPK100M datasheet or visit the Panasonic website for support.
Who is the manufacturer of 16SVPK100M?
Panasonic
