Panasonic 25SEK270M Conductive Polymer Capacitor
The Panasonic 25SEK270M is a radial lead type conductive polymer aluminum solid capacitor, part of the SEK series. It's engineered for high-voltage applications (up to 50V DC) and boasts excellent characteristics including RoHS compliance and halogen-free construction. Designed for a wide temperature range (-55°C to +125°C), this capacitor is suitable for power supplies, inverters, and other demanding applications where stability and reliability are critical. Its endurance rating of +125°C for 1000 hours ensures long-term performance. Refer to the datasheet for detailed specifications and frequency correction factors for ripple current.
Panasonic 25SEK270M Conductive Polymer Capacitor Specifications:
- Size code: E12
- Categorytemperature range: -55°C to +125°C
- Rated voltage range: 25 V.DC to 50 V.DC
- Rated capacitance range: 68 μF to 270 μF
- Capacitance tolerance: ±20 % (120 Hz/+ 20 °C)
- Leakage current: Please see the attached characteristics list
- Dissipation factor: Please see the attached characteristics list
- Endurance: +125°C, 1000 h
- Capacitance change: Within ±20 % of the initial value
- tand: 0.12
- DC leakage current: Within the initial limit
- Damp heat: +60°C, 90 % to 95 %, 1000 h, No-applied voltage
- Ripple current: 1470 mAr.m.s.
- Allowable ripple current: 4650 mAr.m.s.
- ESR: 16 mΩ max.
- LC: 1350 μA
- Frequency correction factor for ripple current: Refer to the frequency correction factor table in the datasheet
