Panasonic 25SEK82M Conductive Polymer Capacitor
The Panasonic 25SEK82M is a radial lead type conductive polymer aluminum solid capacitor designed for a variety of industrial applications. It boasts high voltage capabilities (up to 50V DC), ensuring robust performance in demanding environments. The capacitor is RoHS compliant and halogen-free, aligning with environmental standards. Its endurance rating of +125°C for 1000 hours demonstrates its reliability over extended use. The 25SEK82M is suitable for applications such as power supplies, filtering, and energy storage where a compact, high-performance capacitor is required.
Panasonic 25SEK82M Conductive Polymer Capacitor Specifications:
- Size code: C6
- Categorytemperature range: –55°C to +125°C
- Rated voltage range: 25 V.DC to 50 V.DC
- Rated capacitance range: <br>22 μF to 82 μF
- Capacitance tolerance: ±20 %(120 Hz/+ 20 °C)
- Leakage current: Please see the attached characteristics list
- Dissipation factor(tand): Please see the attached characteristics list
- Endurance: +125°C, 1000 h
- Capacitance change: Within ±20 % of the initial value
- tand: 0.12
- DC leakage current: Within the initial limit
- Damp heat: +60°C, 90 % to 95 %, 1000 h, No-applied voltage
- Ripple current: 960
- Allowable ripple current: 3060
- ESR: 25
- LC: 410
Buy the 25SEK82M PANASONIC Conductive Polymer Capacitor | myMectronic
Purchase the Panasonic 25SEK82M securely and efficiently to ensure your project's success.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic 25SEK82M?
You can click on the BUY or RFQ button to purchase 25SEK82M from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part 25SEK82M?
You can download the 25SEK82M datasheet or visit the Panasonic website for support.
Who is the manufacturer of 25SEK82M?
Panasonic
