Panasonic 25SVPF180M Conductive Polymer Aluminum Capacitor
The Panasonic SVPF series conductive polymer aluminum capacitors are designed for applications requiring high voltage and capacitance. These capacitors offer excellent performance characteristics, including high endurance (+105°C 5000h) and low dissipation factor. They are commonly used in power supplies, DC-DC converters, and other industrial applications where reliable power storage is critical. The capacitors are RoHS compliant and halogen-free, meeting environmental standards. Careful consideration of ripple current and frequency correction factors is recommended for optimal performance.
Panasonic 25SVPF180M Conductive Polymer Aluminum Capacitor Specifications:
- Size code: ['B6', 'C6', 'E7', 'E10', 'E12', 'F10', 'F12']
- Categorytemp. range: –55 ℃ to +105 ℃
- Rated voltage range (V): ['16 to 25', '16 to 50', '16', '16 to 50', '16', '16 to 50']
- Nominal cap.range (μF): ['27 to 82', '10 to 180', '18 to 270', '560', '39 to 560', '1000', '68 to 1000']
- Capacitance tolerance: ±20 %(120 Hz / +20 ℃)
- DC leakage current: Please see the attached characteristics list
- Dissipation factor (tan δ): Please see the attached characteristics list
- Endurance: +105 ℃ 5000 h,rated voltage applied
- Ripple current*1 (mA rms): ['3000', '3300', '3300', '3900', '4950', '4300', '5400']
- ESR*2 (mΩ max.): ['27', '22', '22', '18', '14', '16', '12']
- tan δ*3: ['0.12', '0.12', '0.12', '0.12', '0.12', '0.12', '0.12']
- LC*4 (μA): ['262', '576', '864', '1792', '1792', '3200', '3200']
- Part number: ['16SVPF82M', '16SVPF180M', '16SVPF270M', '16SVPF560MX', '16SVPF560M', '16SVPF1000MX', '16SVPF1000M']
- Min. Packaging Q'ty (pcs): ['1500', '1000', '1000', '500', '400', '500', '400']
Buy the 25SVPF180M PANASONIC Conductive Polymer Aluminum Capacitor | myMectronic
Purchase the Panasonic 25SVPF180M capacitor securely and reliably online for your industrial needs.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic 25SVPF180M?
You can click on the BUY or RFQ button to purchase 25SVPF180M from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part 25SVPF180M?
You can download the 25SVPF180M datasheet or visit the Panasonic website for support.
Who is the manufacturer of 25SVPF180M?
Panasonic
