Panasonic 4SEPC560M Conductive Polymer Aluminum Capacitor
This high-performance conductive polymer aluminum solid capacitor series offers super low ESR, large capacitance up to 2700 UF, and is RoHS and halogen-free compliant. It is designed for power supply filtering, decoupling, and energy storage applications requiring high reliability and stability. Featuring radial lead type with sizes ranging from 5 mm to 16 mm, these capacitors operate within a temperature range of -55°C to +105°C, providing excellent endurance and electrical characteristics for demanding electronic systems. They are suitable for both consumer and industrial electronics where space-saving, efficient energy management, and environmental compliance are critical.
Panasonic 4SEPC560M Conductive Polymer Aluminum Capacitor Specifications:
- Series: SEPC
- Type: Radial Lead
- Operating Temperature Range: -55°C to +105°C
- Capacitance Range: 100 to 2700 UF
- Rated Voltage Range: 2.5 to 16 VDC
- Capacitance Tolerance: +20% (120 Hz / + 20°C)
- Leakage Current: Refer to datasheet
- Dissipation Factor: Refer to datasheet
- Endurance: +105°C, 5000 hours, rated voltage applied
- Size Codes: 5 mm to 16 mm diameter
- ESR: 5 mΩ to 24 mΩ at specified frequencies
- Polarity Marking: Negative terminal indicated (--)
- Material: Conductive polymer and aluminum oxide dielectric
- Compliance: RoHS, Halogen free
- Certifications: UL Listed, REACH compliant
Buy the Buy Panasonic Conductive Polymer Aluminum Capacitors Part Number 4SEPC560M Online
Purchase Panasonic Conductive Polymer Aluminum Capacitors online today for high reliability and superior performance. These capacitors feature ultra low ESR, large capacitance, and excellent endurance, making them ideal for power supply filtering, decoupling, and energy storage in various industrial and consumer electronic systems. RoHS compliant and halogen free, they contribute to environmentally friendly design. With sizes from 5 mm to 16 mm, operating from -55°C to +105°C, they are suited for demanding applications requiring stability, efficiency, and space saving. Order now for fast delivery and quality assurance.
Buy Panasonic 4SEPC560M now and experience unmatched reliability and performance in energy storage and filtering solutions.
Frequently Asked Questions
Where can I buy Panasonic 4SEPC560M?
You can click on the BUY or RFQ button to purchase 4SEPC560M from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part 4SEPC560M?
You can download the 4SEPC560M datasheet or visit the Panasonic website for support.
Who is the manufacturer of 4SEPC560M?
Panasonic
