Panasonic 63SXE18M Conductive Polymer Capacitor
These Panasonic Conductive Polymer Aluminum Solid Capacitors are high-performance, reliable electronic components ideal for industrial applications. Offering super high voltage capability up to 100 V.DC, they feature RoHS compliance and halogen-free construction. Designed with a radial lead type, these capacitors operate within a temperature range of -55°C to +125°C, ensuring durability under demanding conditions. They are available in various sizes and capacitance ratings, with specifications including low ESR, high ripple current, and excellent endurance, making them suitable for high-stability power supply circuits and demanding electronic systems.
Panasonic 63SXE18M Conductive Polymer Capacitor Specifications:
- Category temperature range: -55°C to +125°C
- Rated voltage range: 63 V.DC to 100 V.DC
- Capacitance range: 6.8 UF to 39 UF
- Capacitance tolerance: +20% (120 Hz / +20°C)
- Leakage current and dissipation factor: see attached characteristics list
- Endurance: +125°C, 1000 hours, rated voltage applied, capacitance within +20% of initial
- Leakage current within initial limit after endurance testing
- Dimensions vary by size code, typically around 8.0 mm to 13.0 mm diameter
- Polarity marking: negative (-), with brief polarity marking times
- ESR at 100 kHz: approximately 340 mΩ to 940 mΩ depending on series
- Ripple current capacity: 42 to 110 A at 100 kHz/105°C, corrected for frequency
- RoHS and halogen free, with compliance to safety and quality standards
- Designed for power supply, industrial electronics, and high-density systems adherence
Buy the Panasonic 63SXE18M U+2013 Reliable Conductive Polymer Aluminum Capacitors for Industrial Applications
Purchase Panasonic 63SXE18M conductive polymer aluminum capacitors online today for reliable power management in industrial applications. These capacitors feature high voltage capacity up to 100 V.DC, operate within a wide temperature range from -55°C to +125°C, and are RoHS compliant and halogen free. Designed with low ESR, high ripple current, and excellent endurance, they are perfect for high-stability power supplies and demanding electronic systems. Secure fast shipment, trusted quality, and technical support for your industrial electronic needs with seamless online ordering.
Get Panasonic 63SXE18M today—built for high voltage stability and long-lasting durability in industrial electronics.
Frequently Asked Questions
Where can I buy Panasonic 63SXE18M?
You can click on the BUY or RFQ button to purchase 63SXE18M from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part 63SXE18M?
You can download the 63SXE18M datasheet or visit the Panasonic website for support.
Who is the manufacturer of 63SXE18M?
Panasonic
