Panasonic 63SXV18M High-Voltage Aluminum Capacitor
The Panasonic SXV series conductive polymer aluminum solid capacitors are surface-mount devices designed for high-performance applications. They feature a super high voltage max of 100V DC, RoHS compliance, and are halogen-free. Suitable for industrial electronics, these capacitors operate within a temperature range of -55°C to +125°C, offering reliable endurance at 1000 hours with stable capacitance and minimal leakage current. Their compact size and robust construction make them ideal for demanding power supply andFiltering applications in modern electronic systems.
Panasonic 63SXV18M High-Voltage Aluminum Capacitor Specifications:
- Series: SXV
- Surface Mount Type
- Size code: E7, F8, E12, F12
- Category temperature range: -55°C to +125°C
- Rated voltage range: 63 VDC to 100 VDC
- Capacitance range: 6.8 UF to 68 UF
- Capacitance tolerance: +20% (120 Hz / +20°C)
- Leakage current and dissipation factor: see characteristics list
- Endurance: +125°C, 1000 hours at rated voltage, capacitance within +20% of initial, leakage within initial limit
- Damp heat: within +20% capacitance change after 1000h at 60°C/90-95% RH
- Dimensions: varied per size code with typical length approx. 8-12 mm, width approx. 6.9-12.6 mm, height approx. 20.2-20.3 mm
- Ripple current: up to 1240 mA at 100 kHz/ +105°C
- ESR at 100 kHz: as specified per model
- RoHS compliant, halogen free
Buy the Panasonic 63SXV18M – Reliable Aluminum Solid Capacitors for Industrial Applications
Enhance your electronic projects with Panasonic's high-quality conductive polymer aluminum capacitors. Designed for reliability and efficiency, these surface-mount capacitors operate up to 100V DC and withstand harsh environments from -55°C to +125°C. Compact and RoHS compliant, they are ideal for power supply filtering, industrial automation, and electronic systems requiring stable performance. With robust construction and proven endurance, purchasing these capacitors online guarantees fast delivery, quality assurance, and long-term durability for your critical electronic applications.
Get Panasonic 63SXV18M today—built for high voltage performance and long-lasting durability.
Frequently Asked Questions
Where can I buy Panasonic 63SXV18M?
You can click on the BUY or RFQ button to purchase 63SXV18M from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part 63SXV18M?
You can download the 63SXV18M datasheet or visit the Panasonic website for support.
Who is the manufacturer of 63SXV18M?
Panasonic
