Panasonic 80SXV12M Conductive Polymer Capacitor
Panasonic's 80SXV12M is a conductive polymer aluminum solid capacitor engineered for robust performance in demanding applications. This surface mount capacitor boasts a super high voltage rating, ensuring stability and reliability in power circuits. It is RoHS compliant and halogen-free, aligning with environmental standards. The capacitor's design minimizes internal resistance, contributing to efficient power delivery and reduced heat generation. Typical applications include power supplies, DC-DC converters, and other electronic circuits requiring high capacitance and voltage handling capabilities. Its compact form factor allows for space-saving designs in a variety of devices.
Panasonic 80SXV12M Conductive Polymer Capacitor Specifications:
- Size code: ['E7', 'F8', 'E12', 'F12']
- Category temperature range: –55 °C to +125 °C
- Rated voltage range: 63 V.DC to 100 V.DC
- Rated capacitance range: 6.8 µF to 18 µF
- Capacitance tolerance: ±20 % (120 Hz / + 20 °C)
- Leakage current: Please see the attached characteristics list
- Dissipation factor (tand): Please see the attached characteristics list
- Endurance: +125 °C, 1000 h, rated voltage applied
- Capacitance change: Within ±20 % of the initial value
- tand (limit): <200 % of the initial limit
- DC leakage current (limit): Within the initial limit
- Damp heat: +60 °C, 90 % to 95 %, 1000 h, No-applied voltage
- Marking Dimensions: 0.2 max. W, Polarity marking (−), Lot. No., + L R, Series
- Rated Voltage: 63 V.DC to 100 V.DC
- Capacitance: 6.8 µF to 18 µF
- Ripple current: 340 (E7), 690 (F8), 930 (E12), 1030 (F12)
- Allowable ripple current: 1100, 2190, 2950, 3280
- ESR: 60, 50, 25, 25
- tand: 0.12
- LC: 56, 104, 122, 122
- Part number: ['63SXV18M', '63SXV33M', '63SXV39M', '63SXV39MX', '63SXV68M', '80SXV12M', '80SXV27M', '80SXV27MX', '80SXV47M', '100SXV6R8M', '100SXV15MX', '100SXV15M', '100SXV18M', '100SXV22M']
Buy the 80SXV12M PANASONIC Conductive Polymer Capacitor | myMectronic
Purchase the Panasonic 80SXV12M securely and efficiently through our online platform.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic 80SXV12M?
You can click on the BUY or RFQ button to purchase 80SXV12M from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part 80SXV12M?
You can download the 80SXV12M datasheet or visit the Panasonic website for support.
Who is the manufacturer of 80SXV12M?
Panasonic
