Panasonic ALQ1F09 Industrial Control Relay
The ALQ1F09 is a compact, high-capacity relay suitable for home appliances, industrial equipment, and motor control applications. It features a sealed construction for safety, UL and VDE certification, and Class F insulation. Operating at 24V DC, it offers a contact rating of 10A at 125VAC, 8A at 250VAC, and switch power up to 4150W. The relay has a quick operate time of max 20 ms and durable mechanical lifespan, making it ideal for demanding control systems with reliable performance.
Panasonic ALQ1F09 Industrial Control Relay Specifications:
- Contact arrangement: 1 Form C
- Coil insulation class: Class F
- Nominal coil voltage: 5V, 6V, 12V, 18V, 24V DC
- Contact resistance: Max. 1000 ohms (initial)
- Contact material: AgNi type
- Rating: 10A at 125VAC, 8A at 250VAC, 5A at 30V DC
- Max switching power: 4150 W, 1250 VA
- Insulation resistance: Min. 1,000 MΩ at 500V DC
- Dielectric strength: 4,000 Vrms contact-coil, 8,000 Vrms contact-contact
- Operate time: Max. 20 ms, Release time: Max. 20 ms
- Mechanical life: Min. 10^7 operations at 180 times/min.
- Dimensions: 20 mm length, 10.4 mm width, 16 mm height
- Vibration resistance: Destructive 10-55 Hz, 2.0 mm amplitude
- Temperature range: -55°C to +105°C
Buy the Buy Panasonic Relay Part Number ALQ1F09 Online
Get the Panasonic ALQ1F09 relay online today to enhance your control system with a high-capacity, sealed relay that supports 10A switching at 125VAC—perfect for industrial automation, home appliances, and motor control applications. Its UL and VDE certifications guarantee safety and compliance, making installation straightforward. Designed for durability, with a mechanical lifespan exceeding 10 million cycles, this relay offers quick operation within 20 ms, providing reliable and efficient performance in demanding environments. Purchase online now and secure dependable control for your projects.
Order your Panasonic SeriesALQ1F09 relay today and ensure reliable control with its compact design and high capacity for industrial and appliance use.
Frequently Asked Questions
Where can I buy Panasonic ALQ1F09?
You can click on the BUY or RFQ button to purchase ALQ1F09 from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ALQ1F09?
You can download the ALQ1F09 datasheet or visit the Panasonic website for support.
Who is the manufacturer of ALQ1F09?
Panasonic
