Panasonic AQV252G2S Solid State Relay
The AQV252G2S is a PhotoMOS high-efficiency solid state relay in a SOP 1 Form A package with surface-mount terminals. Designed for fire-preventing and security systems, it handles a peak forward current of 1A and provides at least 1000 MΩ of initial I/O isolation resistance at 500V DC. Operating between -40°C and 85°C, it's suitable for measurement instruments and control applications. Its miniaturized form and high capacity make it ideal for space-saving designs where reliability and electrical performance are critical.
Panasonic AQV252G2S Solid State Relay Specifications:
- Package: SOP 1 Form A, surface-mount
- Peak forward current: 1A
- Load voltage: 50V and 80V
- Continuous load current: 3A maximum
- Operating temperature: -40°C to +85°C
- Isolation voltage: 7,500 V AC
- Initial I/O isolation resistance: over 1000 MΩ at 500V DC
- Power dissipation: 75 mW
- Turn on time: max 0.5 ms
- Turn off time: max 0.5 ms
- LED forward current: 50 mA
- LED reverse voltage: 5 V
- Maximum switching frequency: 25 times/sec
- Output capacitance: max 1.5 pF
Buy the Buy Panasonic AQV252G2S Part Number AQV252G2S Online
Purchase the Panasonic AQV252G2S Solid State Relay online now for dependable performance and high capacity in a compact SOP package. Perfect for fire-preventing and security applications, this relay offers a peak current of 1A, excellent isolation resistance, and operation across a wide temperature range. Its space-saving design ensures easy integration into your equipment. Enjoy fast delivery and competitive pricing by ordering online today, ensuring your projects maintain top efficiency with a trusted, high-quality component.
Order your Panasonic AQV252G2S high-capacity solid state relay today and experience reliable switching in compact package suitable for security and measurement systems.
Frequently Asked Questions
Where can I buy Panasonic AQV252G2S?
You can click on the BUY or RFQ button to purchase AQV252G2S from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part AQV252G2S?
You can download the AQV252G2S datasheet or visit the Panasonic website for support.
Who is the manufacturer of AQV252G2S?
Panasonic
