Panasonic AQW214S Solid State Relay
The AQW214S PhotoMOS GU SOP 2 Form A is a compact, surface-mount relay built with a miniature SOP8-pin package. Designed for automation controls and industrial devices, it operates with load voltages up to 400V and load currents of 0.8A. Its low on resistance and fast switching times ensure reliable performance for high-speed switching applications. Ideal for insulating and switching signals in industrial automation systems, this relay features a wide operating temperature range from -40°C to +85°C and offers excellent isolation and minimal leakage current for dependable operation in industrial environments.
Panasonic AQW214S Solid State Relay Specifications:
- Package: SOP8
- Voltage Type: ACIDC
- Maximum Load Voltage: 400 V
- Maximum Load Current: 0.8 A
- LED Forward Current: 50 mA
- LED Reverse Voltage: 5 V
- Peak Forward Current: 1 A
- Power Dissipation: 75 mW
- On Resistance: Typical 30 ohm, Maximum 50 ohm
- Turn On Time: Typical 1.2 ms, Maximum 2 ms
- Turn Off Time: Typical 0.04 ms, Maximum 0.2 ms
- VO Isolation Voltage: 1500 Vrms
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -40°C to +185°F
- Leakage Current in Off State: Max 1.5 pF
- Recommended Load Voltage: Max 320 V
- Terminal Thickness: 0.15 mm (0.006 inches)
- External Dimensions: Includes detailed mounting pad specifications
Buy the Panasonic AQW214S – Reliable Solid State Relay for Industrial Applications
Purchase the Panasonic AQW214S relay online now to ensure fast delivery and reliable performance in your industrial automation systems. Known for its compact design, high load voltage capacity up to 400V, and low on resistance, this relay provides fast switching times essential for high-speed signal control. Its wide temperature range from -40°C to +85°C makes it suitable for various industrial environments, and the SOP8 package ensures easy mounting and robust operation. Secure your automation projects by ordering online today for quality you can trust in demanding industrial settings.
Order your Panasonic AQW214S series relay today and enhance your industrial automation projects with a dependable, high-performance switching component.
Frequently Asked Questions
Where can I buy Panasonic AQW214S?
You can click on the BUY or RFQ button to purchase AQW214S from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part AQW214S?
You can download the AQW214S datasheet or visit the Panasonic website for support.
Who is the manufacturer of AQW214S?
Panasonic
