Panasonic AQZ204 Industrial Relay
The AQZ204 is a high-capacity, dual-use relay with an output voltage of 400V and a load current of 0.5A, suitable for industrial automation and control applications. Designed with a slim SIL4-pin package, it offers low on-resistance, high I/O isolation voltage of 2,500 V, and eliminates the need for external protection diodes. Perfect for controlling low-level signals, it features low leakage current, robust electrical ratings, and can operate in harsh environments with a temperature range from -40°C to +85°C. The relay is ideal for traffic signals, measuring instruments, and industrial machinery where reliable switching is essential.
Panasonic AQZ204 Industrial Relay Specifications:
- Load voltage: 400V
- Load current: 0.5A
- Package type: SIL4-pin relay
- Isolation voltage: 2,500 VAC
- Control voltage: Suitable for low-level control signals
- Operating temperature: -40°C to +85°C
- Leakage current: Max. 10 pA in off state
- On resistance: Max. 0.550Ω
- Peak load current: 4.5A (Peak AC/DC)
- Dissipation: 1.6W
- Dimensions: Approximate size 3.5 x 21.0 x 12.5 mm
- Materials: Copper alloy contacts, insulating plastic housing
- Certifications: UL Listed, CSA Certified
- Mounting: Suitable for PCB mounting, sockets optional
Buy the Panasonic Series AQZ Series Relay: AQZ204
Purchase the Panasonic Series AQZ204 relay online today and benefit from high load capacity, excellent electrical isolation, and reliable performance in industrial control systems. This SIL4-pin package relay offers low resistance, high insulation voltage, and a compact design suitable for high-density mounting. Ideal for controlling low-level signals, traffic signals, measuring instruments, and machinery, it ensures robust operation at temperatures from -40°C to +85°C. Get the best quality and quick delivery from authorized online suppliers now.
Order your Panasonic Series AQZ204 relay today and ensure reliable switching for industrial automation and high voltage control projects.
Frequently Asked Questions
Where can I buy Panasonic AQZ204?
You can click on the BUY or RFQ button to purchase AQZ204 from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part AQZ204?
You can download the AQZ204 datasheet or visit the Panasonic website for support.
Who is the manufacturer of AQZ204?
Panasonic
