Panasonic AVL38053 Subminiature Switch
The Panasonic AVL38053 is a subminiature switch designed for applications requiring high precision and reliability. Key features include excellent operating position accuracy, flux-resistant construction with integrally molded terminals, and a range of terminal options (solder, PC board, quick-connect). The switch's self-standing terminal structure allows for temporary fixing to a PC board, and the lever pivot position is adjustable. Available with various contact materials (AgNi alloy, CuNi alloy + Au-clad) and operating forces, the AVL38053 is suitable for both standard and low-level circuit applications. It is RoHS compliant and offers a compact design for space-constrained environments.
Panasonic AVL38053 Subminiature Switch Specifications:
- Operating Position Accuracy: Excellent
- Construction: Flux-resistant with integrally molded terminals
- Terminal Types: In-line, Cross-line
- Lever Pivot Position: Adjustable
- Protection Grade: IP40
- Contact Materials: AgNi alloy, CuNi alloy + AgNi alloy + Au-clad
- Operating Force: 0.25N - 1.47N
- Contact Life: Refer to datasheet
- Applicable Current Range: 1mA - 5A
- RoHS Compliant: Yes
