Panasonic CB1RM24V Automotive Relay
This automotive relay features a 24 V DC coil voltage, a single pole double throw (SPDT) contact configuration, and a maximum current rating of 20 amps. It is designed for easy mounting with a bracket and operates as a single side stable relay, suitable for various vehicle electrical applications.
Panasonic CB1RM24V Automotive Relay Specifications:
- Coil Voltage: 24 V DC
- Contact Configuration: Single Pole Double Throw (SPDT)
- Maximum Current Rating: 20 Amps
- Mounting: Bracket type for easy installation
- Operating Mode: Single side stable relay
- Physical Dimensions: External dimensions vary as per type, general tolerance ±0.1 mm
- Contact Resistance: Max. 15 mΩ (initial)
- Contact Material: Silver alloy (Cadmium free)
- Nominal Switching Capacity: 20A 28V DC
- Rated Power Consumption: 1.4W to 2.0W depending on type
- Environmental Resistance: Suitable for automotive environments, sealed options available
- Operating Temperature Range: Not specified in provided data, typically -40°C to +85°C
- Mechanical Durability: Min. 1,000,000 operations
- Vibration Resistance: Functional from 10 Hz to 500 Hz, destructive up to 2,000 Hz
- Shock Resistance: Min. 100G (destructive)
Buy the Panasonic CB1RM24V – Reliable Automotive Relay for Vehicle Electrical Systems
Purchase your Panasonic CB1RM24V automotive relay online today for dependable vehicle electrical performance. Featuring a 20A switch capacity, SPDT contact configuration, and easy bracket mounting, this relay ensures safe and reliable operation in automotive environments. Compact and sealed options available, making installation straightforward and durable. Ideal for headlights, motor controls, and other vehicle electronics, ensuring high durability and resistance to harsh conditions. Secure your vehicle’s electrical system with this trusted, high-quality automotive relay now.
Order your Panasonic CB1RM24V automotive relay today and enhance your vehicle’s electrical reliability with this robust, high-capacity relay.
Frequently Asked Questions
Where can I buy Panasonic CB1RM24V?
You can click on the BUY or RFQ button to purchase CB1RM24V from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part CB1RM24V?
You can download the CB1RM24V datasheet or visit the Panasonic website for support.
Who is the manufacturer of CB1RM24V?
Panasonic
