Panasonic DS1ESDC12V Signal Relay
This signal relay features a 12 V DC coil voltage, single pole double throw SPDT contact configuration, and a maximum current of 2 amps. It is designed for PCB mounting and operates as a single side stable relay, suitable for various control applications.
Panasonic DS1ESDC12V Signal Relay Specifications:
- Coil Voltage: 12 VDC
- Contact Arrangement: Single Pole Double Throw (SPDT)
- Maximum Current: 2A
- Contact Material: Ag+Au clad
- Maximum Switching Voltage: 220V DC, 250V AC
- Rated Switching Capacity: 2A at 30V DC
- Initial Contact Resistance: Max. 50 mΩ
- Insulation Resistance: 1,000 MΩ at 500V DC
- Breakdown Voltage: 7,500 V for open contacts
- Operating Temperature Range: -40°C to +70°C
- Dimensions: Refer to external datasheets for exact measurements
- Mounting: PCB mount, suitable for automated assembly
- Compliance: RoHS Directive compatible
Buy the Matsushita Series DS Signal Relay: DS1ESDC12V
Order the Matsushita DS1ESDC12V signal relay online today and enjoy reliable performance with precise switching, durable construction, and versatile application capabilities. Designed for PCB mounting with a 12-volt coil and SPDT contact configuration, this relay offers a maximum current of 2 amps, making it suitable for various industrial and electronic control systems. Its compact size, high insulation resistance, and RoHS compliance ensure efficient installation and environmentally friendly operation. Enhance your control systems by purchasing this high-quality relay now.
Get Matsushita DS1ESDC12V today—built for precision and long-lasting durability in control applications.
Frequently Asked Questions
Where can I buy Panasonic DS1ESDC12V?
You can click on the BUY or RFQ button to purchase DS1ESDC12V from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part DS1ESDC12V?
You can download the DS1ESDC12V datasheet or visit the Panasonic website for support.
Who is the manufacturer of DS1ESDC12V?
Panasonic
