Panasonic ECA1AHG221 Aluminum Electrolytic Capacitor
The Panasonic ECA-1AHG221 is a radial lead aluminum electrolytic capacitor within the NHG series. Featuring endurance of 105°C for 1000-2000 hours, this capacitor is designed for reliability in various industrial applications. It is RoHS compliant, ensuring adherence to environmental standards. The capacitor's specifications include a capacitance range from 2.2 μF to 22000 μF and a voltage range from 6.3 V.DC to 450 V.DC, making it versatile for diverse circuit designs. Its robust construction and performance characteristics make it a suitable choice for power supplies, filtering, and other critical applications.
Panasonic ECA1AHG221 Aluminum Electrolytic Capacitor Specifications:
- Endurance: 105 °C 1000 h to 2000 h
- RoHS directive compliant: Yes
- Category Temp. Range: -55 °C to +105 °C
- Rated W.V. Range: 6.3 V.DC to 100 V.DC
- Nominal Cap. Range: 2.2 μF to 22000 μF
- Capacitance Tolerance: ±20 % (120 Hz/+20 °C)
- DC Leakage Current: < 0.01 CV or 3 (μA) After 2 minutes
- tan d: Please see the attached standard products list
- Capacitance change: ±20 % of initial measured value
- DC leakage current: < initial specifi ed value
- Lead Dia.: 0.5 to 0.8 mm
- Lead space: 2.0 to 7.5 mm
- Body Dia.: 5 to 18 mm
Buy the ECA-1AHG221 PANASONIC Aluminum Electrolytic Capacitor | myMectronic
Purchase the ECA-1AHG221 Aluminum Electrolytic Capacitor securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic ECA1AHG221?
You can click on the BUY or RFQ button to purchase ECA1AHG221 from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECA1AHG221?
You can download the ECA1AHG221 datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECA1AHG221?
Panasonic
