Panasonic ECA1CM101B Aluminum Electrolytic Capacitor
The Panasonic ECA1CM101B is a radial lead type aluminum electrolytic capacitor suitable for a wide range of applications including power supplies, filtering, and decoupling. It boasts an endurance rating of 85°C for 2000 hours, ensuring long-term reliability. The capacitor is RoHS compliant, meeting environmental standards. Its compact design and robust performance make it a versatile choice for electronic circuit designs. Refer to the attached characteristics list for detailed specifications and performance data.
Panasonic ECA1CM101B Aluminum Electrolytic Capacitor Specifications:
- Endurance: 85 ℃ 2000 h
- Rated Voltage Range: 6.3 V to 100 V, 160 V to 450 V
- Capacitance Range: 2.2 μF to 22000 μF
- Capacitance Tolerance: ±20 % (120 Hz / +20℃)
- Leakage Current: I ≦ 0.01 CV or 3 (μA) After 2 minutes, I ≦ 0.06 CV + 10 (μA) After 2 minutes
- Dissipation Factor: Please see the attached characteristics list
- Capacitance Change: Within ±20 % of the initial value
- DC Leakage Current: Within the initial limit
- Shelf Life: Stabilized at +20 °C, capacitors shall meet the limits specified in endurance. After storage for 1000 h at +85 ℃±2 ℃ with no voltage applied
- Frequency Correction Factor: {'50, 60 Hz (2.2-22000 μF)': '0.70', '120 Hz (2.2-22000 μF)': '1.00', '1 kHz (2.2-22000 μF)': '1.30', '10 kHz (2.2-22000 μF)': '1.70'}
- Dimensions: Refer to datasheet for detailed dimensions
Buy the ECA1CM101B PANASONIC Aluminum Electrolytic Capacitor | myMectronic
Purchase the Panasonic ECA1CM101B aluminum electrolytic capacitor securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic ECA1CM101B?
You can click on the BUY or RFQ button to purchase ECA1CM101B from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECA1CM101B?
You can download the ECA1CM101B datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECA1CM101B?
Panasonic
