Panasonic ECA1CM470I Electrolytic Capacitor
The Panasonic ECA1CM470I is a radial lead type aluminum electrolytic capacitor suitable for a wide range of applications including power supplies, filtering, and decoupling. It features an endurance of 85°C for 2000 hours, ensuring long-term reliability. The capacitor is RoHS compliant, meeting environmental standards. Its compact size and stable performance make it a versatile choice for electronic circuit designs. Refer to the datasheet for detailed specifications and application guidelines.
Panasonic ECA1CM470I Electrolytic Capacitor Specifications:
- Endurance: 85 ℃ 2000 h
- Rated voltage range: 6.3 V to 100 V, 160 V to 450 V
- Capacitance range: 2.2 μF to 22000 μF
- Capacitance tolerance: ±20 % (120 Hz / +20℃)
- Leakage current: I ≦ 0.01 CV or 3 (μA) After 2 minutes, I ≦ 0.06 CV + 10 (μA) After 2 minutes
- Dissipation factor: Please see the attached characteristics list
- Capacitance change: Within ±20 % of the initial value
- DC leakage current: Within the initial limit
- Shelf life: Stabilized at +20 °C, capacitors shall meet the limits specified in endurance. After storage for 1000 h at +85 ℃±2 ℃ with no voltage applied and then being (With voltage treatment)
- Frequency correction factor for ripple current: 0.70-1.70 depending on frequency and capacitance
- Dimensions: Refer to datasheet for detailed dimensions
