Panasonic ECA1EM100 Aluminum Electrolytic Capacitor
The Panasonic ECA-1EM100 is a radial lead aluminum electrolytic capacitor suitable for a wide range of industrial applications. It boasts an endurance rating of 85°C for 2000 hours, ensuring long-term reliability. Compliant with the RoHS directive, this capacitor contributes to environmentally conscious designs. Its compact size and stable performance make it ideal for power supplies, filtering circuits, and other critical applications. The ECA-1EM100 series provides a robust and efficient solution for various electronic systems.
Panasonic ECA1EM100 Aluminum Electrolytic Capacitor Specifications:
- Series: M Type
- Endurance: 85 °C 2000 h
- Capacitance Range: 2.2 μF to 22000 μF
- Rated W.V. Range: 6.3 V.DC to 100 V.DC
- Capacitance Tolerance: ±20 % (120 Hz/+20 °C)
- DC Leakage Current: <0.06 CV +10 (μA) After 2 minutes
- tan d: Please see the attached standard products list
- Frequency Correction Factor (120 Hz): {'50, 60': '0.70', '120': '1.30', '1 k': '1.70', '10 k': '1.00'}
- Body Dia. (0D): 5, 6.3, 8, 10, 12.5, 16, 18 (mm)
- Lead Dia. (0d): 0.5, 0.6, 0.8 (mm)
- Lead Space (F): 2.0, 2.5, 3.5, 5.0, 7.5 (mm)
- Lead Length: 14 min. 3 min.
Buy the ECA-1EM100 PANASONIC Aluminum Electrolytic Capacitor | myMectronic
Purchase the Panasonic ECA-1EM100 Aluminum Electrolytic Capacitor securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic ECA1EM100?
You can click on the BUY or RFQ button to purchase ECA1EM100 from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECA1EM100?
You can download the ECA1EM100 datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECA1EM100?
Panasonic
