Panasonic ECA1EM101I Electrolytic Capacitor Radial
The Panasonic ECA1EM101I is a radial lead type aluminum electrolytic capacitor, part of the M series. It offers a combination of compact size and high capacitance, making it suitable for a wide range of applications including power supplies, filtering, and energy storage. The capacitor boasts an endurance rating of 85°C for 2000 hours, ensuring reliability under demanding conditions. It is also RoHS compliant, meeting environmental standards. The series is no longer available for purchase in Japan. Refer to the characteristics list for detailed specifications and part number variations.
Panasonic ECA1EM101I Electrolytic Capacitor Radial Specifications:
- Endurance: 85 ℃ 2000 h
- Rated Voltage Range: 6.3 V to 100 V, 160 V to 450 V
- Capacitance Range: 2.2 μF to 22000 μF
- Capacitance Tolerance: ±20 % (120 Hz / +20℃)
- Leakage Current: I ≦ 0.01 CV or 3 (μA) After 2 minutes, I ≦ 0.06 CV + 10 (μA) After 2 minutes
- Dissipation Factor: Please see the attached characteristics list
- Capacitance Change: Within ±20 % of the initial value
- DC Leakage Current: Within the initial limit
- Storage Condition: Stabilized at +20 °C, capacitors shall meet the limits specified in endurance.
- Frequency Correction Factor: {'50, 60 Hz (2.2-22000 μF)': '0.70', '120 Hz (2.2-22000 μF)': '1.00', '1 k Hz (2.2-22000 μF)': '1.30', '10 k Hz to (2.2-22000 μF)': '1.70'}
- Dimensions: Refer to datasheet for detailed dimensions
Buy the ECA1EM101I PANASONIC Electrolytic Capacitor Radial | myMectronic
Purchase the Panasonic ECA1EM101I electrolytic capacitor securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic ECA1EM101I?
You can click on the BUY or RFQ button to purchase ECA1EM101I from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECA1EM101I?
You can download the ECA1EM101I datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECA1EM101I?
Panasonic
