Panasonic ECA1VHG330 Aluminum Electrolytic Capacitor
The Panasonic ECA-1VHG330 is a radial lead aluminum electrolytic capacitor suitable for a wide range of industrial applications. It offers a robust design with endurance up to 105°C and is compliant with the RoHS directive. These capacitors are ideal for power supplies, filtering, and other applications requiring stable capacitance and voltage handling. Their radial lead configuration allows for easy integration into various circuit board layouts.
Panasonic ECA1VHG330 Aluminum Electrolytic Capacitor Specifications:
- Endurance: 105 °C 1000 h to 2000 h
- RoHS directive compliant: Yes
- Category Temp. Range: -55 °C to +105 °C
- Rated W.V. Range: 6.3 V.DC to 100 V.DC
- Nominal Cap. Range: 2.2 μF to 22000 μF
- Capacitance Tolerance: ±20 % (120 Hz/+20 °C)
- DC Leakage Current: < 0.01 CV or 3 (μA) After 2 minutes
- tan d: Please see the attached standard products list
- Capacitance change: ±20 % of initial measured value
- DC leakage current: < initial specifi ed value
- Body Dia.: 0D 5 6.3 8 10 12.5 16 18
- Lead Dia.: 0d 0.5 0.5 0.6 0.6 0.6 0.8 0.8
- Lead space F: 2.0 2.5 3.5 5.0 5.0 7.5 7.5
Buy the ECA-1VHG330 PANASONIC Aluminum Electrolytic Capacitor | myMectronic
Purchase the ECA-1VHG330 Aluminum Electrolytic Capacitor securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic ECA1VHG330?
You can click on the BUY or RFQ button to purchase ECA1VHG330 from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECA1VHG330?
You can download the ECA1VHG330 datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECA1VHG330?
Panasonic
