Panasonic ECA2AM330 Aluminum Electrolytic Capacitor
Panasonic's ECA-2AM330 series aluminum electrolytic capacitors are designed for robust performance in various electronic circuits. These radial lead capacitors offer a wide capacitance range and voltage ratings, making them suitable for applications such as power supplies, filtering, and timing circuits. The capacitors are known for their endurance, with a rated lifespan of 2000 hours at 85°C. They are also RoHS compliant, ensuring environmental responsibility. The ECA-2AM330 series provides a reliable and efficient solution for power storage and filtering needs in industrial and consumer electronics.
Panasonic ECA2AM330 Aluminum Electrolytic Capacitor Specifications:
- Endurance: 85 ℃ 2000 h
- Category temp. range: –40 ℃ to +85 ℃
- Rated voltage range: 6.3 V to 100 V, 160 V to 450 V
- Capacitance range: 2.2 μF to 22000 μF
- Capacitance tolerance: ±20 % (120 Hz / +20℃)
- Leakage current: I ≦ 0.01 CV or 3 (μA) After 2 minutes, I ≦ 0.06 CV + 10 (μA) After 2 minutes
- Dissipation factor: Please see the attached characteristics list
- Capacitance change: Within ±20 % of the initial value
- DC leakage current: Within the initial limit
- Shelf life: Stabilized at +20 °C, capacitors shall meet the limits specified in endurance. After storage for 1000 h at +85 ℃±2 ℃ with no voltage applied and then being (With voltage treatment)
- Frequency correction factor for ripple current: See table
- Dimensions: See table
- Lead length: Straight leads, Taping
Buy the ECA-2AM330 PANASONIC Aluminum Electrolytic Capacitor | myMectronic
Purchase the Panasonic ECA-2AM330 securely and efficiently for your electronic component needs.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic ECA2AM330?
You can click on the BUY or RFQ button to purchase ECA2AM330 from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECA2AM330?
You can download the ECA2AM330 datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECA2AM330?
Panasonic
