Panasonic ECEA1AN470U Electrolytic Capacitor
These aluminum electrolytic capacitors are radial lead type, designed for general electronic applications requiring reliable performance and long lifespan. They feature capacities from 2.2 UF to 6800 UF, with a temperature range of -40°C to +85°C and rated voltages from 6.3 V to 50 V. Suitable for use in audio, visual, home appliances, and measuring equipment, these capacitors offer a 2000-hour endurance at 85°C, with low ESR and leakage currents. They are RoHS compliant and designed to ensure safety and durability in various circuit configurations.
Panasonic ECEA1AN470U Electrolytic Capacitor Specifications:
- Category temp. range: -40°C to +85°C
- Rated voltage range: 6.3 V to 50 V
- Capacitance range: 2.2 UF to 6800 UF
- Capacitance tolerance: +20% (120 Hz / +20°C)
- Leakage current: ≤ 0.03 CV + 3 (A) after 5 minutes
- Endurance: 85°C for 2000 hours (1000 hours per polarity)
- RoHS compliant
- Dissipation factor (tan δ): see characteristics list
- Frequency correction factor: 0.70 at 5 Hz, up to 1.70 at 10 kHz
- Physical dimensions: case size varies, lead diameter, length, and pitch specified per model
- Construction: radial lead, case size from 5.0 mm to 18.0 mm diameter
- Application: audio/visual equipment, home appliances, measuring devices, general electronic circuits
- Storage temperature: 5°C to 35°C, humidity 45% to 85%
- Life expectancy: typically 15 years aging limit, with a recommended replacement schedule
- Safety considerations: install with proper pressure relief, avoid reverse voltage, and excessive ripple current
Buy the Buy Panasonic Aluminum Electrolytic Capacitors Part Number ECEA1AN470U Online
Order Panasonic ECEA1AN470U aluminum electrolytic capacitor online today to ensure your electronic circuits operate reliably and efficiently. Designed for general purpose use, these capacitors provide excellent stability, low leakage, and long-term durability. Perfect for audio, visual, and measurement equipment, they are RoHS compliant and built to meet high standards of safety and performance. With fast shipping and trusted quality, you can seamlessly incorporate these capacitors into your designs and projects for optimal electrical operation.
Get Panasonic ECEA1AN470U today—engineered for high reliability and long-lasting electrical performance in your electronic projects.
Frequently Asked Questions
Where can I buy Panasonic ECEA1AN470U?
You can click on the BUY or RFQ button to purchase ECEA1AN470U from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECEA1AN470U?
You can download the ECEA1AN470U datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECEA1AN470U?
Panasonic
