Panasonic ECEA1VN470U Aluminum Electrolytic Capacitor
The ECEA1VN470U is a radial lead aluminum electrolytic capacitor designed for general-purpose electronic applications. It features a capacitance of 470 microfarads with a voltage rating of 25V, suitable for home appliances, audio equipment, and measuring devices. Built with RoHS compliance and rated for an endurance of 2000 hours at 85°C, it offers reliable performance with low leakage current and stable capacitance. Its robust construction ensures stability across temperature variations, making it ideal for a wide range of electronic circuits requiring high reliability and durability.
Panasonic ECEA1VN470U Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 470μF
- Voltage Rating: 25V
- Endurance: 2000 hours at 85°C
- Temperature Range: -40°C to +85°C
- Leakage Current: I S≤ 0.03 CV + 3 (A) After 5 minutes
- Dimensions: ø16mm x 25mm
- Lead Diameter: 0.8 mm
- Ripple Current: 1.1 A rms at 120 Hz / +85°C
- Maximum Lead Spacing: 7.5 mm
- Compliance: RoHS
- Case Size: ø16 mm diameter, length 25 mm
- Rated Voltage Range: 6.3V to 50V
- Capacitance Tolerance: +20% (120Hz / +20°C)
Buy the Panasonic Series SU-A Aluminum Electrolytic Capacitors: 470μF 25V
Enhance your electronic designs with the Panasonic aluminum electrolytic capacitor ideal for general-purpose use. Featuring 470 microfarads capacitance and rated at 25 volts, it guarantees long-lasting performance with an endurance of 2000 hours at 85°C. Its radial lead configuration simplifies installation, making it perfect for home appliances, audio, and measuring equipment. RoHS compliant and rated for temperatures from -40°C to +85°C, this capacitor ensures stable operation, low leakage, and high durability in a compact, reliable package. Upgrade your circuits today!
Buy Panasonic SU-A 470μF 25V aluminum electrolytic capacitor now and experience unmatched reliability and performance for your electronic projects.
Frequently Asked Questions
Where can I buy Panasonic ECEA1VN470U?
You can click on the BUY or RFQ button to purchase ECEA1VN470U from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECEA1VN470U?
You can download the ECEA1VN470U datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECEA1VN470U?
Panasonic
