Panasonic ECWF6333HL Film Capacitor
Panasonic's ECWF series film capacitors are engineered for demanding applications requiring high frequency and high current handling. Utilizing a metallized polypropylene film construction and coated with flame-retardant epoxy resin, these capacitors provide excellent frequency characteristics and low loss. Their non-inductive design minimizes interference and ensures stable performance. Commonly used in lighting systems, high-frequency circuits, and various electronic devices, the ECWF series offers a reliable and compact solution. RoHS compliant for environmentally conscious designs.
Panasonic ECWF6333HL Film Capacitor Specifications:
- Category temp. range: – 40 °C to +105 °C
- Rated voltage: 400 V.DC,630 V.DC
- Capacitance range (400 V.DC): 0.022μF to 2.4μF
- Capacitance range (630 V.DC): 0.010μF to 1.3μF
- Capacitance tolerance: ±3 %(H),±5 %(J)
- Dissipation factor (tand): tand <0.05 % ( 20 °C, 1 kHz )<br>tand <0.20 % ( 20 °C,10 kHz)
- Withstand voltage: Between terminals : Rated volt.(V.DC)×150 %,60 s
- Insulation resistance (IR): C<0.33 μF : IR>9000 MΩ<br>(20 °C, 100 V.DC, 60 s for 400 V.DC)<br>C > 0.33 μF : IR>3000 MΩ∙ μF (20 °C, 500 V.DC, 60 s for 630 V.DC)
