Panasonic ECWFA2J334J Film Capacitor
The Panasonic ECW-FA2J334J is a metallized polypropylene film capacitor engineered for demanding applications requiring high frequency and current handling. Its design incorporates features like low loss, excellent frequency characteristics, and a compact size. This capacitor is RoHS compliant and suitable for use in high frequency and high current circuits, as well as active filter circuits. It is available in various voltage and capacitance ratings to meet diverse design requirements. Always consult factory specifications before purchase and use.
Panasonic ECWFA2J334J Film Capacitor Specifications:
- Category temp. range: –40 ˚C to +105 ˚C
- Rated voltage: 250 VDC, 450 VDC, 630 VDC
- Capacitance range (250 VDC): 0.1 µF to 6.8 µF
- Capacitance range (450 VDC): 0.1 µF to 4.7 µF
- Capacitance range (630 VDC): 0.1 µF to 2.2 µF
- Capacitance tolerance: ±3 % (H), ±5 % (J), ±10 % (K)
- Withstand voltage: Rated voltage (VDC)×150 % 60 s
- Dissipation factor: tanδ≦0.1 % (20 ˚C,1 kHz)
- Insulation resistance: C≦0.33 µF :IR≧9,000 MΩ, C**＞**0.33 µF :IR≧3,000 MΩ·µF (250 VDC), C≦0.33 µF :IR≧30,000 MΩ, C**＞**0.33 µF :IR≧10,000 MΩ·µF (450 VDC), C≦0.33 µF :IR≧9,000 MΩ, C**＞**0.33 µF :IR≧3,000 MΩ·µF (630 VDC)
Buy the ECW-FA2J334J PANASONIC Film Capacitor | myMectronic
Purchase the Panasonic ECW-FA2J334J Film Capacitor securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic ECWFA2J334J?
You can click on the BUY or RFQ button to purchase ECWFA2J334J from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECWFA2J334J?
You can download the ECWFA2J334J datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECWFA2J334J?
Panasonic
