Panasonic ECWFD2J103JB Polypropylene Film Capacitor
The metallized polypropylene film capacitor series offers a reliable, flame-retardant solution suitable for high-frequency circuits and active filter applications. Designed with non-inductive construction, these capacitors feature excellent frequency characteristics, low loss, and minimal noise. Suitable for humid and high-temperature environments, they ensure long-term stability and safety when used within specified voltage and temperature limits. Compliant with RoHS standards, the ECWFD series provides durable performance for demanding electronic and industrial applications, offering options for various voltage ratings, capacitance values, and lead configurations with robust insulation and high dielectric stability.
Panasonic ECWFD2J103JB Polypropylene Film Capacitor Specifications:
- Category temperature range: -40°C to +110°C (450 V), -40°C to +105°C (630 V)
- Rated voltage: 450 V DC, 630 V DC
- Capacitance range: 0.01 pF to 4.7 μF
- Capacitance tolerance: +5 % (J), +10 % (K)
- Dissipation factor (tan δ): tan δ ≤ 0.1 % at 20°C, 1 kHz
- Peak to peak applied voltage: less than 450 V (450 V series), less than 630 V (630 V series)
- Insulation resistance: >30,000 MΩ (C > 0.33 μF), >10,000 MΩ (C ≤ 0.33 μF) at 20°C, 60s
- Withstand voltage: rated voltage x150% for 60 s
- Lead configurations: straight, crimped, cut lead options
- Flame-retardant epoxy coating (94V-0), RoHS compliant
- Dimensions vary by capacitance and voltage, with lead spacing from 5.0 mm to 7.5 mm
- High durability, low hum noise, suitable for humid and high-temperature environments
Buy the Panasonic Series ECWFD Polypropylene Film Capacitor Reliable High-Frequency: ECWFD2J103JB
Buy the Panasonic ECWFD polypropylene film capacitor online today for high-frequency and filter circuit applications. Designed with excellent frequency response, low loss, and flame-retardant epoxy coating, this series guarantees long-term stability and safety across various environments. Perfect for industrial, electronic, and high-temperature applications, it offers a wide capacitance range and options for different lead configurations. Ensure your projects are equipped with reliable, RoHS-compliant capacitors that deliver consistent performance and peace of mind for demanding technical needs.
Order your Panasonic ECWFD series high-frequency polypropylene film capacitor today and give your projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy Panasonic ECWFD2J103JB?
You can click on the BUY or RFQ button to purchase ECWFD2J103JB from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECWFD2J103JB?
You can download the ECWFD2J103JB datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECWFD2J103JB?
Panasonic
