Panasonic ECWFD2W155KC Film Capacitor
The Panasonic ECWFD series is a line of high-quality plastic film capacitors designed for high frequency and active filter circuits. They feature non-inductive construction using metallized polypropylene film with flame retardant epoxy resin coating for enhanced safety and durability. These capacitors offer excellent frequency characteristics, low loss, and low hum sound noise, making them suitable for various electronic applications. They are RoHS compliant and available in different voltage ratings, capacitance ranges, and taping styles to meet diverse circuit requirements. Designed for reliable performance in demanding environments, these capacitors ensure stable operation with precise specifications and long service life.
Panasonic ECWFD2W155KC Film Capacitor Specifications:
- Category temperature range: 450 V —40°C to +110°C, 630 V —40°C to +105°C
- Capacitance range: 0.01 μF to 4.7 μF, Tolerance: +5% (J), +10% (K)
- Dissipation factor (tan δ): 0.1% at 20°C, 1 kHz
- Rated voltage: 450 VDC, 630 VDC
- Peak-to-peak voltage: less than 450 V for 450 V series, less than 630 V for 630 V series
- Withstand voltage: Rated voltage x 150% for 60 seconds
- Insulation resistance: ≥9000 MΩ at 20°C, 500 V
- Self heating temperature rise varies with voltage and frequency; proper derating recommended
- Flame retardant epoxy resin coating (94V-0)
- Dimensions vary depending on capacitance and voltage; maximum lead spacing and taping styles differ per model
- Compatible with automatic insertion and bulk packing, packaging details specified for each series
- Operating temperature limits: Surface temperature within specified derating ratios, avoid use beyond rated upper limit temperatures
- Suitable for high-frequency circuits, filters, and noise suppression with specified permissible currents and voltages
Buy the Buy Panasonic High Frequency Film Capacitors Part Number ECWFD2W155KC Online
Order the Panasonic ECWFD2W155KC film capacitor online today to benefit from high frequency stability, low-loss characteristics, and flame-retardant epoxy coating. Perfect for active filter circuits and RF applications, this high-quality component ensures long-term reliability and excellent performance under demanding conditions. With detailed specifications and various taping options, purchasing online provides convenience and prompt delivery, enabling you to integrate this dependable capacitor into your designs efficiently. Choose Panasonic for superior electronic components and enhance your circuit reliability now.
Buy Panasonic ECWFD2W155KC now and experience reliable high-frequency performance, stability, and safety in your electronic circuit applications.
Frequently Asked Questions
Where can I buy Panasonic ECWFD2W155KC?
You can click on the BUY or RFQ button to purchase ECWFD2W155KC from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECWFD2W155KC?
You can download the ECWFD2W155KC datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECWFD2W155KC?
Panasonic
