Panasonic ECWFD2W824K4 Polypropylene Film Capacitor
The Panasonic ECWFD2W824K4 is a metallized polypropylene film capacitor designed for a variety of applications requiring high performance and reliability. Its non-inductive construction minimizes signal distortion, while the flame-retardant epoxy resin coating enhances safety. This capacitor is well-suited for active filter circuits, high-frequency and high-current applications, and environments demanding robust performance. It is RoHS compliant and available in various lead configurations to meet diverse design requirements.
Panasonic ECWFD2W824K4 Polypropylene Film Capacitor Specifications:
- Category temp. range: －40℃to＋110℃
- Rated voltage: 450 VDC (Derating of rated voltage by 0.62%/˚C at more than 85˚C Peak to peak voltage applied on the capacitor should be less than 240Vp-p, and zero to peak voltage should be less than 450V.)
- Capacitance range: 0.1 µF to 4.7 µF
- Capacitance tolerance: ±5 %(J), ±10 %(K)
- Withstand voltage: Between terminals:Rated voltage (VDC)×150 % 60 s
- Dissipation factor: tanδ≦0.1 % (20 ˚C,1 kHz)
- Insulation resistance: C≦0.33 µF:IR≧30,000MΩ C＞0.33 µF:IR≧10,000MΩ・µF (20℃,100VDC,60 s)
Buy the ECWFD2W824K4 PANASONIC Polypropylene Film Capacitor | myMectronic
Purchase the Panasonic ECWFD2W824K4 capacitor securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic ECWFD2W824K4?
You can click on the BUY or RFQ button to purchase ECWFD2W824K4 from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECWFD2W824K4?
You can download the ECWFD2W824K4 datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECWFD2W824K4?
Panasonic
