Panasonic ECWFE2J154K Polypropylene Film Capacitor
The metallized polypropylene film capacitor series offers non-inductive construction with a flame retardant plastic case, ideal for high-frequency and active filter circuits. Featuring excellent frequency characteristics, low loss, and RoHS compliance, these compact capacitors are designed for reliable operation in power supply and electronic applications. They withstand voltages up to 630V DC, with capacitance from 0.1 to 2.2 μF, and are suitable for noise suppression, AC power supply filtering, and high-frequency circuits, ensuring safety with flame-retardant features and broad environmental compatibility.
Panasonic ECWFE2J154K Polypropylene Film Capacitor Specifications:
- Capacitance range: 0.10 μF to 2.2 μF
- Rated voltage: 450 V DC (ECWFE series), 630 V DC (ECWFE series)
- Capacitance tolerance: +5% (J), +10% (K)
- Temperature range: -40°C to +105°C
- Dimensions vary, typical lengths 13-31 mm depending on model
- Ripple current capacity varies with capacitance and frequency
- Dissipation factor: tan δ ≤ 0.1% at 20°C, 1 kHz
- Withstand voltage: 150% of rated voltage for 60 seconds
- Insulation resistance: ≥ 30,000 MΩ (450V models), ≥ 9,000 MΩ (630V models)
- Lead form: straight or cut lead, with lead pitch from 10 to 27.5 mm
- Flame retardant epoxy resin coating provides safety and environmental compliance
- Designed for high frequency applications, noise suppression, and power filtering
- Compliance: RoHS, safety standards as UL 60384-14, CSA, EN 60384-14
- Shelf life: approx. 6 months under recommended storage conditions
Buy the Panasonic ECWFE2J154K – Reliable Polypropylene Film Capacitor for High-Frequency Filtering
Enhance your electronic projects with Panasonic polypropylene film capacitors, known for their high reliability, low loss, and flame-retardant case. Perfect for high-frequency circuits, noise suppression, and power supply filtering, these compact capacitors are rated up to 630V DC and feature precise capacitance ranges from 0.1 to 2.2 μF. RoHS compliant and built with a flame-retardant epoxy resin coating, they ensure safety and durability in demanding industrial environments. Purchase online now to guarantee high performance and reliable operation in your applications.
Buy Panasonic ECWFE series film capacitors now and experience unmatched reliability and performance in high-frequency filtering and noise suppression.
Frequently Asked Questions
Where can I buy Panasonic ECWFE2J154K?
You can click on the BUY or RFQ button to purchase ECWFE2J154K from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECWFE2J154K?
You can download the ECWFE2J154K datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECWFE2J154K?
Panasonic
