Panasonic ECWH12393JV High-Voltage Film Capacitor
This reliable metallized polypropylene film capacitor features non-inductive construction, flame retardant epoxy resin coating, and excellent electrical characteristics. Suitable for high-frequency, high-voltage circuits such as resonant and inverter applications, it offers rated voltages up to 2000 VDC with capacitance ranges from 0.0036 to 0.10 microfarads. Capable of withstanding temperatures from -55°C to +105°C and compliant with RoHS standards, it ensures durability and safety in demanding industrial environments.
Panasonic ECWH12393JV High-Voltage Film Capacitor Specifications:
- Dielectric: Metallized polypropylene
- Rated Voltage: 1000 V.DC, 1250 V.DC, 1600 V.DC, 2000 V.DC
- Capacitance Range: 0.0036 to 0.10 µF depending on voltage
- Capacitance Tolerance: +3 % (H), +5 % (J)
- Temperature Range: -55°C to +105°C
- Dissipation Factor: 0.1 % (20°C, 1 kHz); 0.2 % (20°C, 10 kHz)
- Insulation Resistance: ≥30,000 MΩ (20°C, 500 V.DC)
- Withstand Voltage: 150% of rated voltage for 60 s, 1500 V.AC for 60 s
- Dimensions: Length approximately 18 mm, height varies by capacitance and voltage
- Packaging: Bulk and taping options available
- RoHS compliant, Flame retardant epoxy coating, Non-inductive construction
Buy the Panasonic ECWH12393JV – Reliable High-Voltage Film Capacitor for Industrial Applications
Purchase the Panasonic ECWH12393JV high-voltage film capacitor online today and ensure your high-frequency, inverter, or resonance circuits operate reliably. With voltages up to 2000 VDC, precise capacitance options, and RoHS compliance, this capacitor is designed for durability and safety in demanding industrial environments. Whether for new projects or replacements, buy online for quick delivery, competitive prices, and expert support. Enhance your electrical systems with our proven metallized polypropylene film capacitor today.
Order your Panasonic ECWH12393JV series high-voltage film capacitor today and upgrade your circuits with our dependable, flame retardant, and RoHS-compliant solution.
Frequently Asked Questions
Where can I buy Panasonic ECWH12393JV?
You can click on the BUY or RFQ button to purchase ECWH12393JV from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECWH12393JV?
You can download the ECWH12393JV datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECWH12393JV?
Panasonic
