Panasonic EEEFK0J151SR Electrolytic Capacitors
High-temperature surface-mount aluminum electrolytic capacitors designed for reliability in industrial applications. With an endurance of 2000 hours at 105°C, these capacitors feature RoHS compliance and vibration-proof construction (30G). They offer a broad voltage range from 6.3V to 50V, with capacitance from 10μF to 1800μF, and excellent stability under varied temperature conditions from -55°C to +105°C. Suitable for use in power supplies, filtering, and snubber circuits, they meet stringent industry standards including AEC-Q200. Their compact SMD design ensures easy assembly and reliable operation across demanding environments.
Panasonic EEEFK0J151SR Electrolytic Capacitors Specifications:
- Category temperature range: -55°C to +105°C
- Rated voltage range: 6.3 V to 50 V DC
- Capacitance range: 10 μF to 1800 μF
- Capacitance tolerance: ±20% (120Hz / +20°C)
- Leakage current: 0.01 CV or 3 (WA) after 2 minutes, whichever is greater
- Endurance: 2000 hours at 105°C ±2°C
- Resistance to soldering heat: Compliant with AEC-Q200 standards
- Impedance at 120 Hz: varies with voltage and size, e.g., 0.26Ω at 6.3V, 150μF
- Vibration-proof: 30G guaranteed upon request
- RoHS compliant: Yes
- Support for reflow soldering: Yes
- Voltage correction factor at frequencies: 120Hz to 100kHz
- Typical size: D8 (6.3x8.0 mm), D (6.3x5.8 mm), G (10x10.2 mm), etc.
- Marking: Black color with negative polarity mark (-)
Buy the Panasonic 151SR – Reliable Aluminum Electrolytic Capacitors for Industrial Applications
Enhance your electronic designs with Panasonic aluminum electrolytic capacitors featuring high-temperature endurance, wide voltage and capacitance ranges, and vibration-proof construction. Perfect for power supplies, filtering, and snubber circuits in industrial applications, these SMD devices ensure reliable performance under harsh conditions. With a compact size, RoHS compliance, and support for reflow soldering, they deliver consistent stability and durability. Invest in Panasonic capacitors today for quality you can trust and peace of mind in your critical projects.
Buy Panasonic 151SR aluminum electrolytic capacitors now and experience unmatched reliability and performance in demanding industrial environments.
Frequently Asked Questions
Where can I buy Panasonic EEEFK0J151SR?
You can click on the BUY or RFQ button to purchase EEEFK0J151SR from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part EEEFK0J151SR?
You can download the EEEFK0J151SR datasheet or visit the Panasonic website for support.
Who is the manufacturer of EEEFK0J151SR?
Panasonic
