Panasonic EEEHA1C100R Aluminum Electrolytic Capacitor
Panasonic's EEE-HA1C100R is a robust surface mount aluminum electrolytic capacitor engineered for demanding environments. Its high-temperature assurance design ensures reliable performance in automotive and industrial applications. The capacitor offers endurance of 105°C for 1000 hours and is available as a vibration-proof product (30G guaranteed) for enhanced durability. AEC-Q200 compliance and RoHS compliance further broaden its applicability across various sectors. The capacitor's compact size and reliable performance make it suitable for a wide range of electronic circuits.
Panasonic EEEHA1C100R Aluminum Electrolytic Capacitor Specifications:
- Endurance: 105 ℃ 1000 h
- Vibration-proof: Available upon request (φ8 ≦)
- AEC Compliance: AEC-Q200 compliant
- RoHS Compliant: Compliant
- Rated Voltage Range: 6.3 V to 100 V
- Capacitance Range: 1μF to 1500μF
- Capacitance Tolerance: ±20 %(120 Hz/+20℃)
- Leakage Current: I ≦ 0.01 CV or 3(μA)After 2 minutes
- Dissipation Factor: Please see the attached characteristics list
- Ripple Current Correction Factor (50/60 Hz): 0.70
- Ripple Current Correction Factor (120 Hz): 1.00
- Ripple Current Correction Factor (1 k Hz): 1.30
- Ripple Current Correction Factor (10 k Hz to): 1.70
- Marking Color: BLACK
- Dimensions (B): {'φD': '4.0', 'L': '5.4', 'A': '4.3', 'B': '5.5'}
- Dimensions (C): {'φD': '5.0', 'L': '5.4', 'A': '5.3', 'B': '6.5'}
- Dimensions (D): {'φD': '6.3', 'L': '5.4', 'A': '6.6', 'B': '7.8'}
- Dimensions (D8): {'φD': '6.3', 'L': '7.7'}
- Dimensions (E): {'φD': '8.0', 'L': '6.2', 'A': '8.3', 'B': '9.5'}
- Dimensions (F): {'φD': '8.0', 'L': '10.2', 'A': '8.3', 'B': '10.0'}
- Dimensions (G): {'φD': '10.0', 'L': '10.2', 'A': '10.3', 'B': '12.0'}
- Land Space (B): 1.0
- Land Space (C): 1.5
- Land Space (D): 1.8
